Service Manual SM CE14A2-C
Ref. No. Part No. Description Ref. No. Part No. Description
10
R124 0790243000 R.M.G. SMD 2,2 KΩ T<=5% 0805
R126 AS2-F 0790239008 R.M.G. SMD 1 KOHM T<=5%
R128 AS2-F 0790239008 R.M.G. SMD 1 KOHM T<=5%
R134 0790251003 R.M.G. SMD 10 KΩ T<=5% 0805
R135 0790251003 R.M.G. SMD 10 KΩ T<=5% 0805
R136 0790239008 R.M.G. SMD 1 KΩ T<=5% 0805
R137 0790138804 Carbon 1 KΩ 5% 1/6W.
R141 0790227003 R.M.G. SMD 100 Ω T<=5% 0805
R1416 0790256002 R.M.G. SMD 27 KΩ T<=5% 0805
R142 0790227003 R.M.G. SMD 100 Ω T<=5% 0805
R143 0790247001 R.M.G. SMD 4,7 KΩ T<=5% 0805
R144 0790247001 R.M.G. SMD 4,7 KΩ T<=5% 0805
R145 A2-E 0790239008 R.M.G. SMD 1 KOHM T<=5%
R146 A2-E 0790239008 R.M.G. SMD 1 KOHM T<=5%
R149 0790233001 R.M.G. SMD 330 Ω T<=5% 0805
R150 0790248009 R.M.G. SMD 5,6 KΩ T<=5% 0805
R151 0790248009 R.M.G. SMD 5,6 KΩ T<=5% 0805
R152 0790248009 R.M.G. SMD 5,6 KΩ T<=5% 0805
R154 0790227003 R.M.G. SMD 100 Ω T<=5% 0805
R155 0790227003 R.M.G. SMD 100 Ω T<=5% 0805
R156 0790247001 R.M.G. SMD 4,7 KΩ T<=5% 0805
R157 0790246003 R.M.G. SMD 3,9 KΩ T<=5% 0805
R158 0790239008 R.M.G. SMD 1 KΩ T<=5% 0805
R160 0790263008 R.M.G. SMD 100 KΩ T<=5% 0805
R161 0790239008 R.M.G. SMD 1 KΩ T<=5% 0805
R162 0790239008 R.M.G. SMD 1 KΩ T<=5% 0805
R163 0790239008 R.M.G. SMD 1 KΩ T<=5% 0805
R165 AS2-F 0790227003 R.M.G. SMD 100 OHM T<=5%
R167 0790138804 Carbon 1 KΩ 5% 1/6W.
R172 0790239008 R.M.G. SMD 1 KΩ T<=5% 0805
R175 0790126700 Carbon 100 Ω 5% 1/6W.
R200 0790138804 Carbon 1 KΩ 5% 1/6W.
R201 0790131106 Carbon 220 Ω 5% 1/4W.
R202 0790235006 R.M.G. SMD 470 Ω T<=5% 0805
R203 0790846109 R.M.G. SMD 220 Ω T<=5% 0805
R204 0790233001 R.M.G. SMD 330 Ω T<=5% 0805
R204 A2-E 0790846109 R.M.G. SMD 220 OHM T<=5%
R204 AS2-F 0790846109 R.M.G. SMD 220 OHM T<=5%
R205 0790749402 R.M.G. SMD 6,8 KΩ T<=5% 0805
R205 A2-E 0790247001 R.M.G. SMD 4,7 KOHM T<=5%
R205 AS2-F 0790247001 R.M.G. SMD 4,7 KOHM T<=5%
R206 0790846109 R.M.G. SMD 220 Ω T<=5% 0805
R207 0790223002 R.M.G. SMD 47 Ω T<=5% 0805
R208 0790223002 R.M.G. SMD 47 Ω T<=5% 0805
R209 0790237002 R.M.G. SMD 680 Ω T<=5% 0805
R209 A2-E 0790242002 R.M.G. SMD 1,8 KΩ 5% 1/10W.
R210 A2-E 0790239008 R.M.G. SMD 1 KΩ 5% 1/10W.
R211 A2-E 0790144505 R.M.G. SMD 2,7 KΩ 5% 1/6W.
R212 0790234009 R.M.G. SMD 390 Ω T<=5% 0805
R213 A2-E 0790144505 R.M.G. SMD 2,7 KΩ 5% 1/6W.
R215
!
0790131908 Carbon 220 Ω 5% 1/6W.
R250 AS2-F 0790151500 Carbón 10 KOHM 5% 1/6W.
R252 0790235006 R.M.G. SMD 470 Ω T<=5% 0805
R253 0790263008 R.M.G. SMD 100 KΩ T<=5% 0805
R254 0790227003 R.M.G. SMD 100 Ω T<=5% 0805
R255 0790252001 Metal GL. RES. 15 KΩ 1% 1/10W.
R256 0790753909 R.M.G. SMD 15 KΩ T<=5% 0805
R257 0790577142 Metal Oxide 12 KΩ 5% 2W.
R258 0790259006 R.M.G. SMD 47 KΩ T<=5% 0805
R259 0790701106 R.M.G. SMD 0 Ω 1/10W. 0805
R261 0790753909 R.M.G. SMD 15 KΩ T<=5% 0805
R262 0790701106 R.M.G. SMD 0 Ω 1/10W. 0805
R262 AS2-F 0790251003 R.M.G. SMD 10 KOHM T<=5%
R263 0790246003 R.M.G. SMD 3,9 KΩ T<=5% 0805
R264 AS2-F 0790145106 Carbón 3,3 KOHM 5% 1/6W.
R265 AS2-F 0790247001 R.M.G. SMD 4,7 KOHM T<=5%
R302 0790757603 R.M.G. SMD 33 KΩ T<=5% 0805
R303 0790251003 R.M.G. SMD 10 KΩ T<=5% 0805
R304 0790275002 R.M.G. SMD 1 MΩ T<=5% 0805
R305 0790128409 Carbon 120 Ω 5% 1/2W.
R316 0790248009 R.M.G. SMD 5,6 KΩ T<=5% 0805
R317 0790111207 Carbon 4,7 Ω 5% 1/4W.
R319 0790160501 Carbon 56 KΩ 5% 1/6W.
R400 0790126700 Carbon 100 Ω 5% 1/6W.
R401 0790126700 Carbon 100 Ω 5% 1/6W.
R402 0790151500 Carbon 10 KΩ 5% 1/6W.
R403 0790227003 R.M.G. SMD 100 Ω T<=5% 0805
R404 0790227003 R.M.G. SMD 100 Ω T<=5% 0805
R405 0790227003 R.M.G. SMD 100 Ω T<=5% 0805
R406 0790234702 R.M.G. SMD 430 Ω T<=5% 0805
R407
!
0790138804 Carbon 1 KΩ 5% 1/6W.
R408
!
0790138804 Carbon 1 KΩ 5% 1/6W.
R412 0790263008 R.M.G. SMD 100 KΩ T<=5% 0805
R413 0790126700 Carbon 100 Ω 5% 1/6W.
R414 0790756308 Carbon 27 KΩ 5% 1/6W.
R416 0790288005 R.M.G. SMD 10 MΩ 5% 1/10W. 0805
R418 0790753909 R.M.G. SMD 15 KΩ T<=5% 0805
R419 0790753909 R.M.G. SMD 15 KΩ T<=5% 0805
R420 0790133102 Carbon 330 Ω 5% 1/4W.
R421 0790232003 R.M.G. SMD 270 Ω T<=5% 0805
R422 0790235006 R.M.G. SMD 470 Ω T<=5% 0805
R423 0790263008 R.M.G. SMD 100 KΩ T<=5% 0805
R424 0790256002 R.M.G. SMD 27 KΩ T<=5% 0805
R425 0790268007 R.M.G. SMD 330 KΩ T<=5% 0805
R426 0790758304 R.M.G. SMD 39 KΩ 1% 1/8W. 0805
R427 0790137707 Carbon 680 Ω 5% 1/6W
R428 0790237002 R.M.G. SMD 680 Ω T<=5% 0805
R430 0790135701 Carbon 470 Ω 5% 1/6W.
R431 0790251003 R.M.G. SMD 10 KΩ T<=5% 0805
R433 0790126700 Carbon 100 Ω 5% 1/6W.
R434 0790126700 Carbon 100 Ω 5% 1/6W.
R435 0790126700 Carbon 100 Ω 5% 1/6W.
R436 0790126700 Carbon 100 Ω 5% 1/6W.
R437 0790126700 Carbon 100 Ω 5% 1/6W.
R600 0790329015 Metal Film 82 Ω 5% 2W
R601 0790142905 Carbon 2 KΩ 5% 1/4W.
R604 0790131601 Carbon 220 Ω 5% 1/2W.
R606 0790539001 Metal Film 18 Ω 5% 1W.
R608 0790512313 Metal Film 0,33 Ω 5% 1W.
R611 0790600001 Metal Film 1 MΩ 1% 0,6W.
R612 0790251003 R.M.G. SMD 10 KΩ T<=5% 0805
R653 0790247001 R.M.G. SMD 4,7 KΩ T<=5% 0805
R655 0790594006 Metal Film 270KΩ 5% 2W.
R670 0470040007 Jumper Lead 0,6 mm.
R676 0790749402 R.M.G. SMD 6,8 KΩ T<=5% 0805
R682 0790259006 R.M.G. SMD 47 KΩ T<=5% 0805
R683 0790259006 R.M.G. SMD 47 KΩ T<=5% 0805
R684 0790247001 R.M.G. SMD 4,7 KΩ T<=5% 0805
R685 0790363105 R.M.G. SMD 18 KΩ T<=5% 0805
R686 0790251003 R.M.G. SMD 10 KΩ T<=5% 0805
R688 0790767503 R.M.G. SMD 220 KΩ T<=5% 0805
R691 0790227003 R.M.G. SMD 100 Ω T<=5% 0805
R702 0790526701 Metal Film 1,5 Ω 1% 0,6W.
R703 0790526701 Metal Film 1,5 Ω 1% 0,6W.
R705 0790136402 Carbon 560 Ω 5% 1/2W.
R706 0790251003 R.M.G. SMD 10 KΩ T<=5% 0805
R708 0790247001 R.M.G. SMD 4,7 KΩ T<=5% 0805
R711 0790343529 Metal Film 1,18 KΩ 1% 0,4W.
R712 0790343529 Metal Film 1,18 KΩ 1% 0,4W.
R800 0790180111 Carbon 2,2 MΩ 5% 1/2W.
R801 0790184113 Carbon 4,7 MΩ 5% 1/2W.
R802 0780147906 Wirewound 3,9 Ω 10% 5W.
R805 0790590111 Metal Film 150 KΩ 5% 2W.
R806 0790330518 Metal Film 100 Ω 5% 2W.
R807 0790161202 R.M.G. SMD 73,2 KΩ 1% 1/8W 0805
R808 0790252001 R.M.G. SMD 15 KΩ 1% 1/10W.
R811 0790275002 R.M.G. SMD 1 MΩ T<=5% 0805
R812 0790245005 R.M.G. SMD 3,3 KΩ T<=5% 0805
R813 0790764005 R.M.G. SMD 120 KΩ T<=5% 0805
R814 0790888101 R.M.G. SMD 9,1 KΩ T<=5% 0805
R815 0790154405 Carbon 18 KΩ 5% 1/6W.
R816 0790027502 Carbon 1 KΩ 5% 1/4W.
R817 0790131106 Carbon 220 Ω 5% 1/4W.
R818 0790027502 Carbon 1 KΩ 5% 1/4W.
R819 0790247001 R.M.G. SMD 4,7 KΩ T<=5% 0805
R820 0790526818 Metal Film 1,5 Ω 5% 2W.
R821 0790526818 Metal Film 1,5 Ω 5% 2W.
R822
0790513014 Fuse 0,33 Ω 5% 0,5W.
R850 0790239008 R.M.G. SMD 1 KΩ T<=5% 0805
R851 0790127104 Carbon 100 Ω 5% 1/4W.
