Service Manual SM CE14A2-C
Ref. No. Part No. Description Ref. No. Part No. Description
11
R852 0790774103 Carbon 820 KΩ 5% 1/6W.
R853 0790767503 R.M.G. SMD 220 KΩ T<=5% 0805
R854 0790258008 R.M.G. SMD 39 KΩ T<=5% 0805
R855 0790767503 R.M.G. SMD 220 KΩ T<=5% 0805
R856 0790167100 Carbon 220 KΩ 5% 1/4W.
R857 0790167100 Carbon 220 KΩ 5% 1/4W.
R858 0790151500 Carbon 10 KΩ 5% 1/6W.
R859 0790135701 Carbon 470 Ω 5% 1/6W.
R860 0790118202 Carbon 18 Ω 5% 1/2W.
R861 0790135909 Carbon 560 Ω 5% 1/6W.
R862 0790239008 R.M.G. SMD 1 KΩ T<=5% 0805
R863 0790343123 Metal Film 1,00 KΩ 1% 0,4W.
R864 0790347009 M.G.R. SMD 1,78 KΩ 1% 1/8W 0805
R865 0790735807 Carbon 510 Ω 5% 1/6W.
R866 0790242002 R.M.G. SMD 1,8 KΩ 5% 1/10W. 0805
R867 0790259006 R.M.G. SMD 47 KΩ T<=5% 0805
R868 0790151500 Carbon 10 KΩ 5% 1/6W.
R869 0790771208 Carbon 470 KΩ 5% 1/6W.
R870 0790247001 R.M.G. SMD 4,7 KΩ T<=5% 0805
R910 0790046403 Carbon 12 KΩ 5% 1/4W.
R911 0790888101 R.M.G. SMD 9,1 KΩ T<=5% 0805
R912 0790026207 Carbon 560 Ω 5% 1/4W.
R913 0790227003 R.M.G. SMD 100 Ω T<=5% 0805
R914 0790129803 Carbon 150 Ω 5% 1/6W.
R915 0790239008 R.M.G. SMD 1 KΩ T<=5% 0805
R916 0790036305 Carbon 2,2 KΩ 5% 1/4W.
R917 0790036305 Carbon 2,2 KΩ 5% 1/4W.
R918 0790229009 R.M.G. SMD 150 Ω T<=5% 0805
R921 0790027502 Carbon 1 KΩ 5% 1/4W.
R922 0790225502 R.M.G. SMD 75 Ω T<=5% 0805
R923 0790225502 R.M.G. SMD 75 Ω T<=5% 0805
R924 0790225502 R.M.G. SMD 75 Ω T<=5% 0805
R925 0790225502 R.M.G. SMD 75 Ω T<=5% 0805
R926 0790225502 R.M.G. SMD 75 Ω T<=5% 0805
R927 0790229009 R.M.G. SMD 150 Ω T<=5% 0805
R928 0790251003 R.M.G. SMD 10 KΩ T<=5% 0805
R929 0790251003 R.M.G. SMD 10 KΩ T<=5% 0805
R930 0790243000 R.M.G. SMD 2,2 KΩ T<=5% 0805
R931 0790151500 Carbon 10 KΩ 5% 1/6W.
R934 0790235006 R.M.G. SMD 470 Ω T<=5% 0805
R935 0790551113 Metal Film 180 Ω 5% 1W.
R941 0790236004 R.M.G. SMD 560 Ω 5% 1/10W. 0805
R942 0790237002 R.M.G. SMD 680 Ω T<=5% 0805
R944 0790236004 R.M.G. SMD 560 Ω 5% 1/10W. 0805
R945 0790237002 R.M.G. SMD 680 Ω T<=5% 0805
R947 0790236004 R.M.G. SMD 560 Ω 5% 1/10W. 0805
R948 0790237002 R.M.G. SMD 680 Ω T<=5% 0805
R952 0790701106 R.M.G. SMD 0 Ω 1/10W. 0805
R953 0790701106 R.M.G. SMD 0 Ω 1/10W. 0805
R954 0790701106 R.M.G. SMD 0 Ω 1/10W. 0805
R1200 AS2-F 0790251003 R.M.G. SMD 10 KOHM T<=5%
R1201 AS2-F 0790243000 R.M.G. SMD 2,2 KOHM T<=5%
R1202 AS2-F 0790245005 R.M.G. SMD 3,3 KOHM T<=5%
R1203 AS2-F 0790251003 R.M.G. SMD 10 KOHM T<=5%
R1204 AS2-F 0790245005 R.M.G. SMD 3,3 KOHM T<=5%
R1205 AS2-F 0790259006 R.M.G. SMD 47 KOHM T<=5%
R1206 AS2-F 0790245005 R.M.G. SMD 3,3 KOHM T<=5%
R1401 AS2-F 0790229009 R.M.G. SMD 150 OHM T<=5%
R1402 AS2-F 0790243000 R.M.G. SMD 2,2 KOHM T<=5%
R1403 AS2-F 0790741805 R.M.G. SMD 1,5 KOHM T<=5%
R1404 AS2-F 0790846109 R.M.G. SMD 220 OHM T<=5%
R1406 AS2-F 0790243000 R.M.G. SMD 2,2 KOHM T<=5%
R1411 AS2-F 0790247001 R.M.G. SMD 4,7 KOHM T<=5%
R1412 AS2-F 0790245005 R.M.G. SMD 3,3 KOHM T<=5%
R1415 AS2-F 0790259006 R.M.G. SMD 47 KOHM T<=5%
R1417 AS2-F 0790259006 R.M.G. SMD 47 KOHM T<=5%
R1418 AS2-F 0790256002 R.M.G. SMD 27 KOHM T<=5%
R1419 AS2-F 0790239008 R.M.G. SMD 1 KOHM T<=5%
R928 AS2-F 0790749402 R.M.G. SMD 6,8 KOHM T<=5%
R929 AS2-F 0790749402 R.M.G. SMD 6,8 KOHM T<=5%
R931 AS2-F 0790149405 Carbón 6,8 KOHM 5% 1/6W.
SF200
!
A2-C 0090411208 SAW Filter G1968M
SF200
!
A2-E 0090403510 SAW Filter K2950M
SF200
!
AS2-F 0090413402 Filtro Onda Superficial K2962M
SF250 AS2-F 0090413600 Filtro Cerámico MKT40.4MA110P
SF1400 AS2-F 0090413501 Filtro Onda Superficial L9453M
SW800
0140204108 Power Switch S-95 WITHOUT WIPER
S300 0330143009 Headphone Jack EK1052
S900 0330161415 Scart Connector 21 PIN BLACK
S901 0330133109 VIDEO RCA Connector EK105Y
S902 0330133208 AUDIO RCA Connector EK105W
TUNER
TU250
!
0850102617 Tuner UV1315/AI-2
TU250
!
AS2-F 0850103201 Tuner UV1315/S I-2
TRANSFORMERS
T600 0940200702 Driver Transformer 360T/40T
T650
0940109200 Split Transformer 14" 10678360
T800
!
0930107511 Switch MODE Transformer EC7A 10679390
VR800 0770511368 VR 2,2 KΩ
X100 0090122300 Quartz Crystal 8MHz
X400 0090121104 Quartz Crystal, 4,4336190 MHz.
ELECTRICAL ASSY
BRDEFL 0010203503 Wire Band 98/2.5 Natural
BRDY 0200099406 Wire HOLDING HOOK G
BRFG 0010203503 Wire Band 98/2.5 Natural
BRRED 0010203503 Wire Band 98/2.5 Natural
CN.FE
0330208216 Power Cord Assy 17-212 L=2000 MM
CN.FF 0330211822 4P Connector W/LEADS 330+25 MM DESF
SC001 0170200406 Shield Mesh 2 mm.
SC1001 0010001311 Spring Ground CRT
SPK1 0030118202 Speaker 8 Ω 2W. 3"
TRC
1000102127 Picture Tube 14"
PACKING
ANT 0330730417 Bipolar Telescopic Antenna W/BALUN
BAT 0660100603 Dry Battery 1,5V. SUM-3F
EM 1 0190203422 Packing Cartoon 14" EXP-C
EM 2 0190160606 Upper Cushion Assy 14" E8R8
EM 3 0190160705 Bottom Cushion Assy 14" E8R8
EM 7
A2-C 0420244006 Instruction Book 14" EC7-A
EM 7
A2-E 0420244105 Instruction Book 14" EC7-A
EM 7
AS2-F 0420244014 Instruction Book 14" EC7-A
EM10 0600123301 Remote Control EC7-A N/TXT SANYO
Note:
All the information of this manual is correct in the beginning of
the series; SANYO reserves the right to modify components and
procedures to maintain its policy of continuous improvement.
