8
TC : Total Cooling Capacity (BTU/h)
SHC : Sensible Heat Capacity (BTU/h)
KW : Compressor Input (kW)
Rating conditions (* mark) are: Outdoor ambient temperature 95°F DB
Indoor unit entering air temperature 80°F DB/67°F WB
Rating Capacity: 11,500 BTU/h Air Flow Rate: 330 CFM
Evaporator Condenser
Ent. Temp. °F (°C) Ambient Temp. °F (°C)
WB DB
75 85 95 105 115
(23.9) (29.4) (35.0) (40.6) (46.1)
TC 11,390 10,870 10,350 9,760 8,970
KW 0.88 0.96 1.04 1.13 1.24
59 72 (22.2) SHC 8,390 8,130 7,870 7,580 7,200
(15.0) 76 (24.4) SHC 9,470 9,210 8,950 8,670 8,290
80 (26.7) SHC 10,610 10,340 10,090 9,760 8,970
84 (28.9) SHC 11,390 10,870 10,350 9,760 8,970
88 (31.1) SHC 11,390 10,870 10,350 9,760 8,970
TC 11,780 11,410 10,960 10,360 9,550
KW 0.89 0.97 1.06 1.15 1.27
63 72 (22.2) SHC 7,050 6,880 6,670 6,400 6,040
(17.2) 76 (24.4) SHC 8,130 7,960 7,750 7,490 7,120
80 (26.7) SHC 9,260 9,090 8,890 8,620 8,260
84 (28.9) SHC 10,350 10,180 9,970 9,700 9,340
88 (31.1) SHC 11,430 11,260 10,960 10,360 9,550
TC 12,100 11,900 *11,500 10,870 10,120
KW 0.89 0.98 1.07 1.17 1.29
67 72 (22.2) SHC 5,660 5,580 5,410 5,150 4,850
(19.4) 76 (24.4) SHC 6,750 6,670 6,500 6,230 5,930
80 (26.7) SHC 7,880 7,800 7,630 7,370 7,060
84 (28.9) SHC 8,970 8,880 8,710 8,450 8,150
88 (31.1) SHC 10,050 9,970 9,800 9,540 9,230
TC 12,480 12,270 11,960 11,420 10,750
KW 0.90 0.99 1.09 1.20 1.32
71 72 (22.2) SHC 4,240 4,160 4,040 3,840 3,590
(21.7) 76 (24.4) SHC 5,330 5,250 5,130 4,930 4,680
80 (26.7) SHC 6,460 6,380 6,260 6,060 5,810
84 (28.9) SHC 7,540 7,460 7,350 7,140 6,900
88 (31.1) SHC 8,630 8,550 8,430 8,230 7,980
TC 12,720 12,580 12,310 11,870 11,390
KW 0.92 1.01 1.10 1.23 1.35
75 76 (24.4) SHC 3,910 3,860 3,770 3,620 3,460
(23.9) 80 (26.7) SHC 5,040 5,000 4,900 4,750 4,590
84 (28.9) SHC 6,130 6,080 5,990 5,840 5,680
88 (31.1) SHC 7,210 7,170 7,070 6,920 6,760
Indoor unit KHS1232
Outdoor unit CH1232
208V single phase 60Hz
