Outdoor temperature (°F DB)
0
10
20
30
40
50
60
70
80
90
100
110
120
Heating capacity ratio (%)
NOTE
1) … Point of rating condition
Black dot in the chart indicates the following rating condition.
Indoor : 70°F DB
Outdoor : 47°F DB / 43°F WB
2) Above characteristics indicate instantaneous operation, which does not take into
consideration defrost operation.
3) Fan speed : High
47 50 6040302017
5. HEATING CAPACITY
