- 9 -
PARTS LIST
REF.NO. PART NO. DESCRIPTION
DISPLAY P.W.BOARD ASSY
REF.NO. PART NO. DESCRIPTION
72 614 320 1755 ASSY,PWB,DISPLAY(Only initial)
(240,130 series)
72 614 321 0795 ASSY,PWB,DISPLAY(Only initial)
(128 series)
CN701 645 051 6542 6P HEADER
CN702 645 051 6528 3P HEADER(240,130 series)
CN703 645 051 6559 8P HEADER
CN705 645 051 6511 2P HEADER
D0701 645 023 6099 DIODE 1N-4148
D0703 645 023 6099 DIODE 1N-4148
D0704 645 023 6099 DIODE 1N-4148
D0705 645 023 6099 DIODE 1N-4148
D0706 645 023 6099 DIODE 1N-4148
D0707 645 023 6099 DIODE 1N-4148
D0708 645 023 6099 DIODE 1N-4148
D0709 645 023 6099 DIODE 1N-4148
D0710 645 023 6099 DIODE 1N-4148
D0711 645 023 6099 DIODE 1N-4148
D1201 645 033 3477 DIODE RPM-6938-V4(240,130 series)
Q0701 645 033 3521 TR 2SA1317S AC
Q0702 645 033 3521 TR 2SA1317S AC
Q0703 645 023 6129 TR 9014C
Q0704 645 023 6129 TR 9014C
SW701 645 042 0023 SW TACT,MEMORY
SW702 645 042 0023 SW TACT,REPEAT
SW703 645 042 0023 SW TACT,FB-B-SCAN
SW704 645 042 0023 SW TACT,FF-F-SCAN
SW705 645 042 0023 SW TACT,STOP/CLEAR
SW706 645 042 0023 SW TACT,PLAY/PAUSE
645 042 0078 LED DISPLAY
645 042 0795 LED BRACKET
645 051 6481 LED ROUND TYPE,REPEAT
645 051 6481 LED ROUND TYPE,MEMORY
645 051 6481 LED ROUND TYPE,PLAY/PAUSE
645 023 6594 SCREW ST 3X8
645 023 6617 SCREW ST 3X10
645 033 0285 COPPER WIRE,JW701,702
645 027 1267 COPPER WIRE,JW703
REC SW P.W.BOARD ASSY
REF.NO. PART NO. DESCRIPTION
73 614 320 1779 ASSY,PWB,REC SW(Only initial)
645 051 6498 5P CONNECTOR,TO MAIN CN204
SW801 645 033 3569 PUSH SW,PS-22F03
TUNER P.W.BOARD ASSY
REF.NO. PART NO. DESCRIPTION
74 614 320 1748 ASSY,PWB,TUNER(Only initial)(XE)
74 614 321 0788 ASSY,PWB,TUNER(Only initial)(UK)
74 614 321 0825 ASSY,PWB,TUNER(Only initial)
(MX)(CA)
74 614 321 0849 ASSY,PWB,TUNER(Only initial)
(AU)(PA)
C0114 403 056 8905 POLYESTER 1000P M 50V
C0120 645 051 6443 POLYESTER 140PF
C0129 403 059 0708 POLYESTER 0.018U M 50V
C0130 403 059 0708 POLYESTER 0.018U M 50V
CF102 645 051 6450 CERAMIC FILTER
CF103 645 027 0291 CERAMIC FILTER(Except UK,XE)
CF103 645 041 9966 CERAMIC FILTER(UK,XE)
CF104 645 051 6467 BAND PASS FILTER
CN101 645 051 6535 5P HEADER,V- TYPE
CT105 645 033 4771 TRIMMER 20PF(UK)
CT106 645 033 4771 TRIMMER 20PF(UK)
D0101 645 023 6099 DIODE 1N-4148
D0102 645 023 6099 DIODE 1N-4148
D0103 645 023 6082 DIODE 1S-2638,AFC
D0104 645 023 6105 ZENER DIODE
D0105 645 023 6099 DIODE 1N-4148
IC101 645 041 9973 IC LA1824
L0104 645 023 6297 VHF COIL
L0105 645 032 9944 FTZ COIL,BH-816557
L0106 645 024 1024 AM COIL
L0107 645 042 0016 LW COIL(UK)
PVC01 645 026 6676 PVC,AM/FM
SW101 645 042 0047 SW SLIDE SS22E01G6,2 BAND SW
(Except UK)
SW101 645 042 0061 SW SLIDE SS63D01GT6,3 BAND SW
(UK)
SW102 645 024 1048 SW SLIDE SK22F03G6,
MONO & BEAT CUT SW
T0101 645 026 6669 AM OSC,OSC 1010
T0102 645 026 6669 AM OSC,OSC 1010(UK)
T0103 645 027 0437 FM IFT,IF 0070
T0104 645 033 3866 AM COIL,IF 2070
T0105 645 027 0444 FM IFT,IF 0380
645 042 0184 HSG 1PIN,FM ANT
645 042 0344 CONTACT PIN,FM ANT
645 033 0285 COPPER WIRE
645 027 1267 COPPER WIRE,
645 014 4646 COPPER WIRE
645 027 1274 COPPER WIRE,
645 023 6594 SCREW ST 3X8
645 051 6320 ASSY BAR ANT(Except UK)
645 051 6337 ASSY BAR ANT(UK)
645 024 1055 FERRITE BAR(Except UK)
645 025 4338 FERRITE BAR( UK)
645 051 6658 BAR ANT HOLDER
RECTIFIER P.W.BOARD ASSY
REF.NO. PART NO. DESCRIPTION
75 614 320 1762 ASSY,PWB,RECTIFIER(Only initial)
(All except MX,CA)
75 614 321 0801 ASSY,PWB,RECTIFIER(Only initial)
(MX,CA)
C1105 403 135 0400 ELECT 3300U M 25V
D0401 645 033 3859 ZENER 8.2V
D1101 645 023 6112 RECTIFIER 1N-4001(240/MX)(130/CA)
D1102 645 023 6112 RECTIFIER 1N-4001
D1103 645 023 6112 RECTIFIER 1N-4001
D1104 645 023 6112 RECTIFIER 1N-4001
F1101 645 035 0092 GLASS TUBE FUSE 2 A,FS1101
(All except MX,CA)
F1101 645 051 6504 FUSE GLASS TUBE,FS1101(MX,CA)
N1101 645 027 0611 WAFER 4P,CN1101
Q0401 645 033 3507 TR 2SD2061E
645 035 0511 FUSE HOLDER MW1010K
645 042 0320 HEAT SINK
645 023 6594 SCREW ST 3X8
645 023 6686 SCREW M3X8,FOR IC
645 033 0285 COPPER WIRE,JW1101,1102
645 027 1298 EYELET
645 027 1397 NUT
