PARTS LIST
REF.NO. PART NO. DESCRIPTION REF.NO. PART NO. DESCRIPTION
56
!
!!
645 035 0092 GLASS TUBE FUSE 2 A,FS1101
(All except MX,CA)
56
!
!!
645 051 6504 FUSE GLASS TUBE,FS1101(MX,CA)
57 645 041 9928 ROD ANTENNA,2 SECTION
!
!!
645 023 6358 SW SLIDE SS12J01M65(PA)
645 051 6696 PVC PLATE,FOR VOLTAGE HOLE
(Except PA)
!
!!
645 027 0352 CHOKE COIL 100UH,MOTOR
645 033 3606 FERRITE BEAD,
CABLE ACROSS CD PCB(128 series)
645 042 0191 HSG 4PINS,
CN1102 TO RECTIFIER CN11
(128 series)
645 042 0221 SHIELD W TRIPPLE COR,
CASS DECK TO MAIN
645 042 9569 HSG 6P,TO CD DECK
645 042 9590 HSG 2P,TO CTL CN705
645 044 9284 FERRITE BEAD,FORMER PRIMARY
WIRE(All except 128 sereis)
645 051 6474 FERRITE BEAD,FORMER PRIMARY
WIRE(128 sereis)
645 044 9284 FERRITE BEAD,FORMER
SECONDARY WIRE(Except 128 sereis)
645 051 6474 FERRITE BEAD,FORMER
SECONDARY WIRE(128 sereis)
645 051 6566 3P HSG,TO CTL CN702
(All except 128 sereis)
645 051 6573 4P HSG,CN1102 TO RECTIFIER CN11
(All except 128 sereis)
645 051 6580 4P HSG,SPK TO MAIN CN301
645 051 6597 5P HSG,TO TUN CN101
645 051 6603 6P HSG,TO CTL CN701
645 051 6610 8P HSG,CD CN907/CN908 TO CTL CN
645 051 6627 3P HSG,MOTOR TO MAIN CN302
645 051 6634 2P HSG,
CD DOOR SW TO MAIN CN904
645 051 6665 BUFFER,EMC X 8
CD MAIN/AMP P.W.BOARD ASSY
REF.NO. PART NO. DESCRIPTION
71 614 320 1731 ASSY,PWB,CD MAIN/AMP(Only initial)
(130/PA)(130/UK)(130/AU)(130/XE)
71 614 321 0818 ASSY,PWB,CD MAIN/AMP(Only initial)
(MX, CA)
71 614 321 0832 ASSY,PWB,CD MAIN/AMP(Only initial)
(128 series)
C0201 403 060 6904 POLYESTER 3300P M 50V
C0202 403 060 6904 POLYESTER 3300P M 50V
C0207 403 059 6908 POLYESTER 0.022U M 50V
C0208 403 059 6908 POLYESTER 0.022U M 50V
C0209 403 059 4409 POLYESTER 2200P M 50V
C0210 403 059 4409 POLYESTER 2200P M 50V
C0223 403 059 4409 POLYESTER 2200P M 50V
C0224 403 059 6908 POLYESTER 0.022U M 50V
C0225 403 057 1202 POLYESTER 0.01U M 50V
C0310 403 058 6008 POLYESTER 0.15U M 50V
C0311 403 058 6008 POLYESTER 0.15U M 50V
C0315 403 045 1801 ELECT 1000U M 25V
C0501 403 060 6904 POLYESTER 3300P M 50V
C0502 403 060 6904 POLYESTER 3300P M 50V
C0505 403 058 6008 POLYESTER 0.15U M 50V
C0506 403 058 6008 POLYESTER 0.15U M 50V
C0901 403 059 4409 POLYESTER 2200P M 50V
C0902 403 057 3800 POLYESTER 0.1U M 50V
C0903 403 057 3800 POLYESTER 0.1U M 50V
C0904 403 062 1105 POLYESTER 0.047U M 50V
C0905 403 060 6904 POLYESTER 3300P M 50V
C0908 403 060 8908 POLYESTER 0.033U M 50V
C0909 403 057 3800 POLYESTER 0.1U M 50V
C0911 403 062 1105 POLYESTER 0.047U M 50V
C0912 403 063 0800 POLYESTER 6800P M 50V
C0928 403 060 8908 POLYESTER 0.033U M 50V
C0930 403 057 1202 POLYESTER 0.01U M 50V
C0932 403 060 8908 POLYESTER 0.033U M 50V
C0933 403 059 0708 POLYESTER 0.018U M 50V
C0934 403 060 6904 POLYESTER 3300P M 50V
C0939 403 060 6904 POLYESTER 3300P M 50V
C0940 403 057 3800 POLYESTER 0.1U M 50V
C0951 403 062 5905 POLYESTER 5600P M 50V
C0952 403 062 5905 POLYESTER 5600P M 50V
C0963 403 057 3800 POLYESTER 0.1U M 50V
CF901 645 042 0115 RESONATOR 16.934MHZ
CN301 645 027 0611 WAFER 4P
CN302 645 032 9982 HEADER 3PINS
CN901 645 042 0177 FFC HEADER 15PINS,
TO PICK UP ASSY
CN904 645 042 9538 HEADER 2PINS,CD LEAF SW
D0301 645 023 6112 RECTIFIER 1N-4001
D0305 645 023 6099 DIODE 1N-4148
D0306 645 023 6099 DIODE 1N-4148
D0901 645 023 6099 DIODE 1N-4148
D0903 645 023 6099 DIODE 1N-4148
D0904 645 023 6099 DIODE 1N-4148
D0905 645 023 6099 DIODE 1N-4148
D0906 645 023 6099 DIODE 1N-4148
D0907 645 023 6099 DIODE 1N-4148
IC201 645 033 4696 IC TA2068N
IC301 645 049 9890 IC LA4627
IC901 645 041 9980 IC LA9250M
IC902 645 041 9997 IC LC78602YE
IC903 645 044 3022 IC MM1469XH
IP901 645 033 4672 IC PROTECTOR N15,ICP901
JK301 645 033 3743 EARPHONE JACK
L0301 645 044 1721 FERRITE BEAD
L0302 645 044 1721 FERRITE BEAD
L0303 645 044 1721 FERRITE BEAD
L0901 645 042 0108 CHOKE COIL 26UH
Q0201 645 033 3491 TR 2SC945P
Q0202 645 023 6129 TR 9014C
Q0301 645 023 6129 TR 9014C
Q0302 645 023 6129 TR 9014C
Q0901 645 033 3521 TR 2SA1317S AC
Q0902 645 041 9959 TR 2SA1346AC
Q0903 645 033 3514 TR 2SB764D
Q0904 645 041 9959 TR 2SA1346AC
Q0905 645 033 3538 TR 2SD1936S AC
Q0906 645 033 3538 TR 2SD1936S AC
Q0907 645 023 6129 TR 9014C
R0303 402 071 1304 FUSIBLE RES 2.2 JA 1/4W
R0304 402 071 1304 FUSIBLE RES 2.2 JA 1/4W
SW301 645 042 0054 SW SLIDE,SS23E01G6
SW501 645 042 0030 SW PUSH,ON-OFF
T0201 645 027 0307 BIAS COIL,IFT 3630
VR301 645 042 0085 ROTARY VR,SHAFT VOL
645 027 1267 COPPER WIRE
645 027 1267 COPPER WIRE
645 027 1281 COPPER WIRE
645 027 1298 EYELET
645 027 1397 NUT
645 033 0285 COPPER WIRE
645 033 0285 COPPER WIRE
645 033 0322 TUBE COTTON SLEEVE
645 042 0337 HEAT SINK
645 043 9803 HEAT SINK
