PARTS LIST
CAUTION : Regular type resistors and capacitors are not listed. To know those values, refer to the schematic diagram.
Regular type resistors are less than 1/4 W carbon type and 0 ohm chip resistors.
Regular type capacitors are less than 50 V and less than 1000 µF type of Ceramic type and Electrical type.
N.S.P : Not available as service parts.
PRODUCT SAFETY NOTICE
EACH PRECAUTION IN THIS MANUAL SHOULD BE FOLLOWED DURING SERVICING. COMPONENTS IDENTIFIED WITH THE
IEC SYMBOL
!
!!
IN THE PARTS LIST AND THE SCHEMATIC DIAGRAM DESIGNATED COMPONENTS IN WHICH SAFETY AND
PERFORMANCE CAN BE OF SPECIAL SIGNIFICANCE. WHEN REPLACING A COMPONENT IDENTIFIED BY
!
!!
, USE ONLY THE
REPLACEMENT PARTS DESIGNATED, OR PARTS WITH THE SAME RATINGS OF RESISTANCE, WATTAGE OR VOLTAGE THAT
ARE DESIGNATED IN THE PARTS LIST IN THIS MANUAL. LEAKAGE-CURRENT OR RESISTANCE MEASUREMENTS MUST BE
MADE TO DETERMINE THAT EXPOSED PARTS ARE ACCEPTABLY INSULATED FROM THE SUPPLY CIRCUIT BEFORE
RETURNING THE PRODUCT TO THE CUSTOMER.
REF.NO. PART NO. DESCRIPTION
PACKING & ACCESSORIES
REF.NO. PART NO. DESCRIPTION
614 333 9694 CARTON CASE
614 329 2494 CUSHION,REAR
614 329 2487 CUSHION,FRONT
614 333 9717 INSTRUCTION MANUAL
645 046 8322 ASSY,ANTENNA,LOOP
645 076 7067 REMOCON,RB-DA1160
614 333 8048 LID,BATTERY
614 333 2954 ASSY,BOX,SPEAKER
CABINET & CHASSIS
REF.NO. PART NO. DESCRIPTION
1 614 333 3159 ASSY,DOOR,DECK
2 614 329 2449 SPRING,DOOR DECK
3 614 333 2961 BUTTON,VOLUME
4 614 333 3173 ASSY,PANEL FRONT
5 614 309 7969 ASSY,GEAR,CASSETTE
6 614 333 3708 HOLDER,BUTTON VOLUME
7 614 333 3715 SPRING,BUTTON,VOLUME
8 614 333 2985 DEC,WINDOW BUTTON
9 614 329 2159 BUTTON,LEFT,3 KEYS
10 614 329 2135 BUTTON,FUNC,4 KEYS
11 614 329 2166 BUTTON,RIGHT,2 KEYS
12 614 329 2265 KNOB,DECK MECHA,REC
13 614 329 2272 KNOB,DECK MECHA,PLAY
14 614 329 2289 KNOB,DECK MECHA,REW
15 614 329 2296 KNOB,DECK MECHA,FFWD
16 614 329 2302 KNOB,DECK MECHA,STOP/EJECT
17 614 329 2319 KNOB,DECK MECHA,PAUSE
18 614 329 2340 MOUNTING,DECK MECHA
19 614 333 3388 ASSY,MECHA,TK20FX-S898001
20 614 308 0534 SPRING,PLATE,REC
21 614 310 3899 SPACER,MECHA,CD+DA11
22 614 325 6014 ASSY,MECHA,DA11T3CN-SASH
or 614 333 0387 ASSY,MECHA,DA11V
23 614 307 2072 COVER,PICK-UP
24 614 322 2132 ASSY,GEAR,LID,CD
25 614 329 2357 MOUNTING,CD
26 614 303 0263 LATCH,PUSH,CD DOOR LOCKING
27 614 307 8821 PULLEY
28 614 303 0256 LATCH,MAGNET
29 614 329 2456 SPRING,DOOR CD
30 614 334 0324 LID,CD
31 614 334 0317 DEC,WINDOW CD
32 614 333 9663 ASSY,CABINET,REAR
FIXING PARTS
REF.NO. PART NO. DESCRIPTION
Y01 412 071 3000 SPECIAL SCREW 3.0X10.0,
BUT VOL+HOLDER BUT VOL
Y02 411 193 8603 SCR S-TPG BRZ+FLG 3X10,GEAR
Y03 411 021 3404 SCR S-TPG BIN 3X10,
PANEL+MTG DECK KNOB
Y04 411 021 3404 SCR S-TPG BIN 3X10,
PANEL+DECK MECHA
ELECTRICAL PARTS
REF.NO. PART NO. DESCRIPTION
51 614 309 8454 ASSY,WIRE,CD TO CD MECHA
52 614 330 3459 FLEXIBLE FLAT CABLE,CD PICK UP
53 423 032 8101 FUSE 250V 2.5A
54 614 333 8086 FLEXIBLE FLAT CABLE,
TUNER TO FRONT
55 614 333 8079 FLEXIBLE FLAT CABLE,
AMP TO FRONT
56 614 274 2013 CORD,ID CONNECTOR,FM ANT
57 645 068 8973 TRANS,POWER
58 645 068 1059 CORD,POWER-2.0MK
FRONT P.W.BOARD ASSY
REF.NO. PART NO. DESCRIPTION
71 614 333 7683 ASSY,PWB,FRONT(Only initial)
BR601 614 329 2241 HOLDER,LCD
C6200 403 259 0508 NP-ELECT 1U M 50V
or 403 373 7001 NP-ELECT 1U M 50V
CN601 645 009 4187 SOCKET,FFC 14P,MCON-AMP
CN602 645 059 0498 SOCKET,FPC 16P,FRONT-TU
D6201 407 235 7406 LED LT7V34-81-URC1,LCD_LIGHT
D6901 407 012 4406 DIODE 1SS133
D6902 407 012 4406 DIODE 1SS133
IC601 410 574 1905 IC LC723341E-9C91-E
Y05 411 021 3404 SCR S-TPG BIN 3X10,
FRONT PWB+MOUNT
Y06 411 021 3404 SCR S-TPG BIN 3X10,
MTG CD+CD PCB
Y07 411 021 1608 SCR S-TPG BIN 2.6X10,
MTG CD+MECHA CD
Y08 411 194 8503 WASHER Z 2.6X10X0.5,
MECHA,CD+MOUNTING
Y09 411 098 4205 SCR S-TPG BIN 3X8,
MTG CD+TUNER PCB
Y10 411 021 3404 SCR S-TPG BIN 3X10,
MTG CD+ASSY,GEAR
Y11 411 123 9106 SCR S-TPG BIN 3X20,
PANEL+MOUNTING
Y12 411 021 3404 SCR S-TPG BIN 3X10,
MTG CD+AMP PCB
Y13 411 021 3404 SCR S-TPG BIN 3X10,
REAR+PWB POWER
Y14 411 191 4201 SCR S-TPG BRZ+FLG 3X12,
REAR+P-TRANS
Y15 411 021 3404 SCR S-TPG BIN 3X10,
REAR+STOPPER
Y16 411 098 7800 SCR S-TPG FLT 3X12,
PANEL+REAR+MOUNTING
Y17 411 126 4108 SCR S-TPG BIN 3X16,PANEL+REAR
Y18 411 021 3404 SCR S-TPG BIN 3X10,
MTG CD+REAR
Y19 411 021 3404 SCR S-TPG BIN 3X10,
C-REAR(ANT TERMINAL)
