- 6 -

PARTS LIST

REF.NO. PART NO. DESCRIPTION REF.NO. PART NO. DESCRIPTION

MAIN P.W.BOARD ASSY

REF.NO. PART NO. DESCRIPTION

74 614 333 2312 ASSY,PWB,MAIN(Only initial)

C4714 403 058 4608 POLYESTER 0.15U J 50V

C4814 403 058 4608 POLYESTER 0.15U J 50V

C4913 403 329 6003 ELECT 4700U M 25V

C4918 403 056 7502 POLYESTER 1000P J 50V

or 403 377 6307 POLYESTER 1000P J 50V

CN401 645 006 1875 PLUG,2P,SPEAKER

or 645 078 1889 PLUG,PWB 2P

CN402 645 006 1875 PLUG,2P,SPEAKER

or 645 078 1889 PLUG,PWB 2P

CN405 645 004 2904 PLUG,4P

or 645 078 2428 PLUG,4P

CN406 614 310 2458 PLUG,4P

or 645 005 8110 PLUG,4P

CN411 645 004 2881 PLUG,2P,POWER

or 645 078 1605 PLUG,2P,POWER

CN421 645 011 6384 JACK,PHONE D3.6,HEADPHONE

or 645 055 1017 JACK,PHONE D3.6,HEADPHONE

CN490 645 012 2750 SOCKET,DIP 10P

CN491 645 009 4187 SOCKET,FFC 14P

CN492 614 333 7904 ASSY,WIRE

D4951 407 099 6003 ZENER DIODE MTZJ9.1B

D4953 407 012 4406 DIODE 1SS133

D4960 407 012 4406 DIODE 1SS133

D4961 407 012 4406 DIODE 1SS133

D4963 407 012 4406 DIODE 1SS133

D4964 407 012 4406 DIODE 1SS133

D4965 407 012 4406 DIODE 1SS133

D4966 407 012 4406 DIODE 1SS133

D4967 407 012 4406 DIODE 1SS133

D4968 407 012 4406 DIODE 1SS133

D4969 407 012 4406 DIODE 1SS133

D4970 407 012 4406 DIODE 1SS133

D4971 407 149 0807 DIODE 1SS355

D4980 407 098 3300 DIODE RL153-BF-S2

D4981 407 098 3300 DIODE RL153-BF-S2

D4982 407 098 3300 DIODE RL153-BF-S2

D4983 407 098 3300 DIODE RL153-BF-S2

D4984 407 098 3300 DIODE RL153-BF-S2

D4993 407 012 4406 DIODE 1SS133

FCL41 645 031 7903 HOLDER,FUSE

or 645 006 4760 HOLDER,FUSE

FCL42 645 031 7903 HOLDER,FUSE

or 645 006 4760 HOLDER,FUSE

HS401 614 332 1514 HEAT SINK

IC410 409 384 3506 IC BA3314F

IC411 409 521 9507 IC CD4052BCM

IC412 410 509 6203 IC LC75344M-D-MPB-E

IC413 409 612 2202 IC KIA6282K

IC446 409 039 9204 IC NJM78L05A

L4780 645 002 1459 INDUCTOR,22U K

L4781 645 002 1459 INDUCTOR,22U K

L4881 645 002 1459 INDUCTOR,22U K

L4902 645 031 5893 TRANS,OSC,85KHZ,O.S.C

L4997 645 001 5519 INDUCTOR,47U K,AMP EMC USE

L4998 645 001 5519 INDUCTOR,47U K,AMP EMC USE

L4999 645 037 2858 CORE,PIPE,AMP EMC USE

LG401 645 006 4432 FIXER

PR495 645 066 9743 PROTECTOR,1.5A 125V

PR496 645 066 9743 PROTECTOR,1.5A 125V

Q4106 405 146 2206 TR KTC3875-GR

or 405 011 1006 TR 2SC1623-L6

or 405 014 4509 TR 2SC2412K-R

XF212 614 240 2917 FILTER,CERAM

or 645 010 7665 CERAMIC FILTER 10.70MHZ

or 645 054 1223 CERAMIC FILTER 10.70MHZ

XF215 645 041 9324 CERAMIC FILTER 450KHZ

or 645 059 0054 CERAMIC FILTER 450KHZ

Q4107 405 146 2206 TR KTC3875-GR

or 405 011 1006 TR 2SC1623-L6

or 405 014 4509 TR 2SC2412K-R

Q4320 405 143 8706 TR KTC3199-GR

or 405 011 8500 TR 2SC1740S-R

or 405 011 8609 TR 2SC1740S-S

or 405 017 9600 TR 2SC3330-T

or 405 017 9709 TR 2SC3330-U

Q4321 405 141 3406 TR KTA1266-GR

or 405 141 3505 TR KTA1266-Y

or 405 004 4502 TR 2SA608-F-NP

or 405 004 5004 TR 2SA608-G-NP

Q4740 405 141 3604 TR KTA1273-Y

or 405 009 5207 TR 2SB927-S

or 405 009 5306 TR 2SB927-T

Q4751 405 021 0600 TR 2SD1012-G-SPA

or 405 033 6706 TR 2SD1468S-R

or 405 033 6805 TR 2SD1468S-S

or 405 021 0204 TR 2SD1012-F-SPA

or 405 151 4400 TR KTD1303

Q4840 405 141 3604 TR KTA1273-Y

or 405 009 5207 TR 2SB927-S

or 405 009 5306 TR 2SB927-T

Q4851 405 151 4400 TR KTD1303

or 405 021 0204 TR 2SD1012-F-SPA

or 405 021 0600 TR 2SD1012-G-SPA

or 405 033 6706 TR 2SD1468S-R

or 405 033 6805 TR 2SD1468S-S

Q4902 405 019 2708 TR 2SC536-F-NP

or 405 019 3804 TR 2SC536-G-NP

or 405 141 3208 TR KTC3198-Y

or 405 141 3307 TR KTC3198-GR

Q4904 405 143 8706 TR KTC3199-GR

or 405 011 8500 TR 2SC1740S-R

or 405 011 8609 TR 2SC1740S-S

or 405 017 9600 TR 2SC3330-T

or 405 017 9709 TR 2SC3330-U

Q4951 405 158 2102 TR KTC2026-Y

or 405 138 6403 TR KTD2058Y

or 405 095 1602 TR 2SD2061-E

or 405 095 1701 TR 2SD2061-F

Q4990 405 019 3804 TR 2SC536-G-NP

or 405 019 2708 TR 2SC536-F-NP

or 405 141 3208 TR KTC3198-Y

or 405 141 3307 TR KTC3198-GR

Q4991 405 141 3604 TR KTA1273-Y

or 405 009 5207 TR 2SB927-S

or 405 009 5306 TR 2SB927-T

Q4992 405 141 3406 TR KTA1266-GR

or 405 141 3505 TR KTA1266-Y

or 405 004 4502 TR 2SA608-F-NP

or 405 004 5004 TR 2SA608-G-NP

Q4994 405 143 0007 TR KRC107M

or 405 000 3806 TR DTC114YS

Q4995 405 141 3703 TR KTA1271-Y

or 405 008 2405 TR 2SB698-F

or 405 008 2504 TR 2SB698-G

Q4996 405 141 3307 TR KTC3198-GR

or 405 141 3208 TR KTC3198-Y

or 405 019 2708 TR 2SC536-F-NP

or 405 019 3804 TR 2SC536-G-NP

Q4997 405 019 3804 TR 2SC536-G-NP

or 405 019 2708 TR 2SC536-F-NP

or 405 141 3307 TR KTC3198-GR

or 405 141 3208 TR KTC3198-Y

R4752 402 071 1304 FUSIBLE RES 2.2 JA 1/4W

R4852 402 071 1304 FUSIBLE RES 2.2 JA 1/4W

R4941 401 121 8607 MT-FILM 27 FD 1/4W

S4950 645 038 7586 SWITCH,PUSH,R/PSW

S4951 645 077 0821 SWITCH,SLIDE

SA401 411 098 4205 SCR S-TPG BIN 3X8,

HEAT SINK-413/Q4951

SA402 411 098 4205 SCR S-TPG BIN 3X8,

HEAT SINK-413/Q4951
