- 11 -

PARTS LIST

REF.NO. PART NO. DESCRIPTION

or 405 011 8609 TR 2SC1740S-S

or 405 017 9600 TR 2SC3330-T

or 405 017 9709 TR 2SC3330-U

Q4905 405 143 8706 TR KTC3199-GR

or 405 011 8500 TR 2SC1740S-R

or 405 011 8609 TR 2SC1740S-S

or 405 017 9600 TR 2SC3330-T

or 405 017 9709 TR 2SC3330-U

Q4951

405 138 6403 TR KTD2058Y

405 095 1602 TR 2SD2061-E

405 095 1701 TR 2SD2061-F

R4104 401 105 0702 MT-GLAZE 100K JA 1/16W

R4105 401 105 0603 MT-GLAZE 10K JA 1/16W

R4106 401 105 0603 MT-GLAZE 10K JA 1/16W

R4107 401 105 5400 MT-GLAZE 47K JA 1/16W

R4703 401 105 5806 MT-GLAZE 56 JA 1/16W

R4704 401 105 4601 MT-GLAZE 3.9K JA 1/16W

R4705 401 105 2102 MT-GLAZE 18K JA 1/16W

R4708 401 105 2102 MT-GLAZE 18K JA 1/16W

R4709 401 105 0504 MT-GLAZE 1K JA 1/16W

R4710 401 105 4601 MT-GLAZE 3.9K JA 1/16W

R4716 401 105 0504 MT-GLAZE 1K JA 1/16W

R4717 401 105 1600 MT-GLAZE 15K JA 1/16W

R4718 401 105 1402 MT-GLAZE 150 JA 1/16W

R4730 401 105 2904 MT-GLAZE 22K JA 1/16W

R4731 401 105 1204 MT-GLAZE 120K JA 1/16W

R4732 401 105 4205 MT-GLAZE 33K JA 1/16W

R4733 401 105 4106 MT-GLAZE 3.3K JA 1/16W

R4734 401 105 5301 MT-GLAZE 4.7K JA 1/16W

R4735 401 105 4601 MT-GLAZE 3.9K JA 1/16W

R4736 401 105 5400 MT-GLAZE 47K JA 1/16W

R4737 401 105 2102 MT-GLAZE 18K JA 1/16W

R4738 401 105 0504 MT-GLAZE 1K JA 1/16W

R4739 401 105 5400 MT-GLAZE 47K JA 1/16W

R4740 401 105 2904 MT-GLAZE 22K JA 1/16W

R4741 401 105 3406 MT-GLAZE 27K JA 1/16W

R4742 401 105 0603 MT-GLAZE 10K JA 1/16W

R4743 401 105 0702 MT-GLAZE 100K JA 1/16W

R4745 401 105 1105 MT-GLAZE 12K JA 1/16W

R4746 401 105 7503 MT-GLAZE 82K JA 1/16W

R4747 401 105 8203 MT-GLAZE 68K JA 1/16W

R4748 401 105 2904 MT-GLAZE 22K JA 1/16W

R4749 401 105 2904 MT-GLAZE 22K JA 1/16W

R4750 401 105 2904 MT-GLAZE 22K JA 1/16W

R4751 401 105 2904 MT-GLAZE 22K JA 1/16W

R4752

402 071 1304 FUSIBLE RES 2.2 JA 1/4W

R4753 401 105 2201 MT-GLAZE 180K JA 1/16W

R4756 401 105 5301 MT-GLAZE 4.7K JA 1/16W

R4760 401 105 0603 MT-GLAZE 10K JA 1/16W

R4761 401 105 0504 MT-GLAZE 1K JA 1/16W

R4770 401 105 5400 MT-GLAZE 47K JA 1/16W

R4781 401 105 1402 MT-GLAZE 150 JA 1/16W

R4782 401 105 6001 MT-GLAZE 5.6K JA 1/16W

R4803 401 105 5806 MT-GLAZE 56 JA 1/16W

R4804 401 105 4601 MT-GLAZE 3.9K JA 1/16W

R4805 401 105 2102 MT-GLAZE 18K JA 1/16W

R4808 401 105 2102 MT-GLAZE 18K JA 1/16W

R4809 401 105 0504 MT-GLAZE 1K JA 1/16W

R4810 401 105 4601 MT-GLAZE 3.9K JA 1/16W

R4816 401 105 0504 MT-GLAZE 1K JA 1/16W

R4817 401 105 1600 MT-GLAZE 15K JA 1/16W

R4818 401 105 1402 MT-GLAZE 150 JA 1/16W

R4830 401 105 2904 MT-GLAZE 22K JA 1/16W

R4831 401 105 1204 MT-GLAZE 120K JA 1/16W

R4832 401 105 4205 MT-GLAZE 33K JA 1/16W

R4833 401 105 4106 MT-GLAZE 3.3K JA 1/16W

R4834 401 105 5301 MT-GLAZE 4.7K JA 1/16W

R4835 401 105 4601 MT-GLAZE 3.9K JA 1/16W

REF.NO. PART NO. DESCRIPTION

CN441 614 310 2731 PLUG,2P,POWER

or 645 004 2881 PLUG,2P,POWER

CN490 645 012 2736 SOCKET,DIP 8P

CN491 645 012 5096 SOCKET,FPC 12P

CN492 614 314 4809 ASSY,WIRE

or 614 309 8812 ASSY,WIRE

D4102 407 012 4406 DIODE 1SS133

D4951

407 099 6003 ZENER DIODE MTZJ9.1B

D4953 407 012 4406 DIODE 1SS133

D4961 407 012 4406 DIODE 1SS133

D4962 407 012 4406 DIODE 1SS133

D4963 407 012 4406 DIODE 1SS133

D4964 407 012 4406 DIODE 1SS133

D4980

407 098 3300 DIODE RL153-BF-S2

D4981

407 098 3300 DIODE RL153-BF-S2

D4982

407 098 3300 DIODE RL153-BF-S2

D4983

407 098 3300 DIODE RL153-BF-S2

FCL41

645 006 4760 HOLDER,FUSE

645 031 7903 HOLDER,FUSE

FCL42

645 006 4760 HOLDER,FUSE

645 031 7903 HOLDER,FUSE

HS401 614 315 2873 HEAT SINK

IC410 409 384 3506 IC BA3314F

IC411 409 390 1107 IC LC75392

IC412

409 295 7402 IC TA8229K

IC415 409 469 6200 IC MM1453XF

L4781 645 006 9864 INDUCTOR,80U

L4881 645 006 9864 INDUCTOR,80U

L4902 645 031 5893 TRANS,OSC,85KHZ,O.S.C

PR495

645 042 2621 PROTECTOR,1.5A 125V

PR496

645 042 2621 PROTECTOR,1.5A 125V

Q4103 405 000 0508 TR DTA114ES

or 405 110 5400 TR KRA102M-A

Q4104 405 109 9204 TR KRC102M-A

or 405 000 3103 TR DTC114ES

Q4106 405 000 3103 TR DTC114ES

or 405 109 9204 TR KRC102M-A

Q4730 405 143 6504 TR KTA1267-GR

or 405 004 4601 TR 2SA608-F-SPA

or 405 004 5103 TR 2SA608-G-SPA

or 405 006 1806 TR 2SA933S-R

or 405 006 1905 TR 2SA933S-S

Q4751 405 033 6706 TR 2SD1468S-R

or 405 151 4400 TR KTD1303

or 405 021 0204 TR 2SD1012-F-SPA

or 405 021 0600 TR 2SD1012-G-SPA

or 405 033 6805 TR 2SD1468S-S

Q4830 405 004 4601 TR 2SA608-F-SPA

or 405 004 5103 TR 2SA608-G-SPA

or 405 006 1806 TR 2SA933S-R

or 405 006 1905 TR 2SA933S-S

or 405 143 6504 TR KTA1267-GR

Q4851 405 151 4400 TR KTD1303

or 405 021 0204 TR 2SD1012-F-SPA

or 405 021 0600 TR 2SD1012-G-SPA

or 405 033 6706 TR 2SD1468S-R

or 405 033 6805 TR 2SD1468S-S

Q4902 405 011 8609 TR 2SC1740S-S

or 405 017 9600 TR 2SC3330-T

or 405 017 9709 TR 2SC3330-U

or 405 011 8500 TR 2SC1740S-R

or 405 143 8706 TR KTC3199-GR

Q4903 405 151 4400 TR KTD1303

or 405 021 0204 TR 2SD1012-F-SPA

or 405 021 0600 TR 2SD1012-G-SPA

or 405 033 6706 TR 2SD1468S-R

or 405 033 6805 TR 2SD1468S-S

Q4904 405 143 8706 TR KTC3199-GR

or 405 011 8500 TR 2SC1740S-R
