Sanyo DC-DA70 - Wiring Connection Diagram; Inter-Board Wiring

- 42 -
WIRING CONNECTION
MOTOR
SWITCH
R/P HEAD
RED
ORANGE
YELLOW
BROWN
M
TAPE DECK MECHANISM
L-CH
SPEAKER
BOX
R-CH
SPEAKER
BOX
CD MECHANISM
CD P.W.B
FRONT P.W.B
LED P.W.B
BOARD TO BOARD
LCD60
CN441
(2P)
CN406
(4P)
CN491
(12P)
CN421
PHONES
CN490
(8P)
CN402
(2P)
CN401
(2P)
CN422
(2P)
CN601
(12P)
CN603
(17P)
CN602
(2P)
CN122
(8P)
CN111
(15P)
(15P)
CN113
(6P)
(6P)
CN201
CN203
(1P)
CN202
(17P)
CN405
(4P)
FU401
T2A L 250V
BK RE
BR
P.T
POWER SUPPLY P.W.B
AMP P.W.B
TUNER P.W.B
AM LOOP
ANT.
FM
ANT.
BL
AC IN
230-240V 50Hz (AU)
110-120V/220-240V 50/60Hz (PA)
