PARTS LIST
PRODUCT SAFETY NOTICE
EACH PRECAUTION IN THIS MANUAL SHOULD BE FOLLOWED DURING SERVICING. COMPONENTS IDENTIFIED WITH THE IEC
SYMBOL
!
!!
IN THE PARTS LIST AND THE SCHEMATIC DIAGRAM DESIGNATED COMPONENTS IN WHICH SAFETY CAN BE OF
SPECIAL SIGNIFICANCE. WHEN REPLACING A COMPONENT IDENTIFIED BY
!
!!
, USE ONLY THE REPLACEMENT PARTS DESIGNATED,
OR PARTS WITH THE SAME RATINGS OF RESISTANCE, WATTAGE OR VOLTAGE THAT ARE DESIGNATED IN THE PARTS LIST
IN THIS MANUAL. LEAKAGE-CURRENT OR RESISTANCE MEASUREMENTS MUST BE MADE TO DETERMINE THAT EXPOSED
PARTS ARE ACCEPTABLY INSULATED FROM THE SUPPLY CIRCUIT BEFORE RETURNING THE PRODUCT TO THE CUSTOMER.
CAUTION : Regular type resistors and capacitors are not listed. To know those values, refer to the schematic diagram.
Regular type resistors are less than 1/4 W carbon type and 0 ohm chip resistors.
Regular type capacitors are less than 50 V and less than 1000 µF type of Ceramic type and Electrical type.
PACKING & ACCESORIES
REF.NO. PART NO. DESCRIPTION
614 308 1487 CARTON CASE (AU)
614 308 1494 CARTON CASE (PA)
614 307 2423 CUSHION,REAR
614 307 2430 CUSHION,FRONT
614 308 1623 INSTRUCTION MANUAL (AU)
614 308 1630 INSTRUCTION MANUAL (PA)
614 231 6832 LABEL,SAFETY,CLASS1
645 041 1571 POLY SHEET-0340X0280*NC,SET
645 037 9833 POLY BAG-0180X0250*NC,
1AV0L90B00200
614 309 3435 NOTICE (AU)
645 005 1227 ASSY,ANTENA,LOOP
645 040 3217 REMOCON,RB-DA70
or 645 042 3604 REMOCON,RB-DA70
or 645 042 3611 REMOCON,RB-DA70
614 312 2173 ASSY,BOX,SPEAKER
645 006 4630 PLUG,ADAPTOR AC (PA)
or 645 017 2175 PLUG,ADAPTOR AC (PA)
CABINET & CHASSIS
REF.NO. PART NO. DESCRIPTION
1 614 307 1952 ASSY,DOOR,DECK
2 614 309 7969 ASSY,GEAR,CASSETTE
3 614 310 4940 ASSY,PANEL,FRONT
4 614 307 2188 KNOB,VOLUME
5 614 307 2195 KNOB,DECK,MECHA,REC
6 614 307 2201 KNOB,DECK,MECHA,PLAY
7 614 307 2218 KNOB,DECK,MECHA,REW
8 614 307 2225 KNOB,DECK,MECHA,FFWD
9 614 307 2232 KNOB,DECK,MECHA,STOP/EJECT
10 614 307 2249 KNOB,DECK,MECHA,PAUSE
11 614 307 2270 MOUNTING,DECK,KNOB
12 614 307 2263 LID,CASSETTE
13 614 308 5058 SPRING,DOOR,DECK
14 614 308 1197 ASSY,CABINET,REAR (AU)
14 614 308 1203 ASSY,CABINET,REAR (PA)
15 614 307 2003 BUTTON,POWER,1 KEY
16 614 307 2010 BUTTON,FUNCTION,10 KEYS
17 614 307 2027 BUTTON,CD OPEN,1 KEY
18 614 307 8784 LEVER
19 614 307 8722 BUTTON,PUSH,1 KEY
20 614 307 2034 BUTTON,BASS,1 KEY
21 614 311 7872 ASSY,LID,CD,1 KEY
22 614 303 0256 LATCH,MAGNET
23 614 307 8821 PULLEY
24 614 308 0534 SPRING,REC
25 614 307 2393 SPRING,DOOR CD
26 614 307 2072 COVER,PICK-UP
FIXING PARTS
REF.NO. PART NO. DESCRIPTION
Y01 411 021 3503 SCR S-TPG BIN 3X10,
F-PANEL+MTG DECK KNOB
Y02 411 020 8905 SCR S-TPG BRZ+FLG 3X10,GEAR
Y03 411 021 4005 SCR S-TPG BIN 3X12,REAR+STOPPER
Y04 411 020 9100 SCR S-TPG BRZ+FLG 3X12,
REAR+P-TRANS
Y05 411 021 3503 SCR S-TPG BIN 3X10,
C-REAR(ANT TERMINAL)
Y06 411 021 1806 SCR S-TPG BIN 2.6X10,MTG CD+DA11
Y07 411 092 0906 WASHER Z 2.6X10X0.5,MTG CD+DA11
Y08 411 021 3503 SCR S-TPG BIN 3X10,
REAR+DECK MECHA
Y09 411 021 4500 SCR S-TPG BIN 3X16,C-REAR
Y10 411 098 7800 SCR S-TPG FLT 3X12,
C-REAR(L/R SIDE)
Y11 411 126 1404 SCR S-TPG BIN 2X4,
SPRING DECK REC
Y12 411 021 6405 SCR S-TPG BIN 3X8,
MTG CD+ASSY,GEAR
Y13 411 021 3503 SCR S-TPG BIN 3X10,
MTG CD+FRONT PCB
Y14 411 021 3503 SCR S-TPG BIN 3X10,
MTG CD+TUNER PCB
Y15 411 021 3503 SCR S-TPG BIN 3X10,
MTG CD+CD PCB
Y16 411 021 3503 SCR S-TPG BIN 3X10,MTG CD+REAR
ELECTRICAL PARTS
REF.NO. PART NO. DESCRIPTION
51
!
!!
645 032 1887 CORD,POWER-1.74MK (AU)
51
!
!!
645 016 9939 CORD,POWER-1.74MK (PA)
52 614 310 5466 FLEXIBLE FLAT CABLE (CN102)
53 614 309 8454 ASSY,WIRE (CN103)
55 614 309 8805 ASSY,WIRE,MECHA SW-AMP (CN405)
56 614 309 8799 ASSY,WIRE,R/P HEAD-AMP (CN406)
57 614 310 5459 FLEXIBLE FLAT CABLE (CN604)
58
!
!!
423 016 7908 FUSE 250V 2.5A
59
!
!!
645 040 8113 POWER TRANSFORMER (AU)
59
!
!!
645 040 8120 POWER TRANSFORMER (PA)
614 310 6210 FLEXIBLE FLAT CABLE,
FRONT TU MAIN (CN403)
614 274 2013 CORD,ID CONNECTOR (E2101)
REF.NO. PART NO. DESCRIPTION
27 614 307 2287 MOUNTING,CD
28 614 310 1673 ASSY,GEAR,LID,CD
29 614 308 4914 STOPPER
30 614 310 3899 SPACER,MECHA
31 614 274 8190 LABEL,SAFETY,LASER PICK UP
