- 6 -

PARTS LIST

AMPLIFIER P.W.BOARD ASSY

REF.NO. PART NO. DESCRIPTION

71 614 310 4094 ASSY,PWB,AMP,AMP-TU

(AU) (Only Initial)

71 614 310 4919 ASSY,PWB,AMP,AMP-TU

(PA) (Only Initial)

C4714 403 058 4608 POLYESTER 0.15U J 50V

C4716 403 350 8403 ELECT 1000U M 16V

or 403 313 4602 ELECT 1000U M 16V

C4814 403 058 4608 POLYESTER 0.15U J 50V

C4816 403 313 4602 ELECT 1000U M 16V

or 403 350 8403 ELECT 1000U M 16V

C4913 403 329 5907 ELECT 3300U M 25V

or 403 350 9301 ELECT 3300U M 25V

C4918 403 056 7502 POLYESTER 1000P J 50V

CN401 645 006 1875 PLUG,2P,SPEAKER

CN402 645 006 1875 PLUG,2P,SPEAKER

CN405 645 004 2904 PLUG,4P

CN406 645 005 8110 PLUG,4P

CN421 645 011 6384 JACK,PHONE D3.6,HEADPHONE

CN441 645 004 2881 PLUG,2P,POWER

CN490 645 012 2736 SOCKET,DIP 8P

CN491 645 012 5096 SOCKET,FPC 12P

CN492 614 309 8812 ASSY,WIRE

D4102 407 012 4406 DIODE 1SS133

D4951

407 099 6003 ZENER DIODE MTZJ9.1B

D4953 407 012 4406 DIODE 1SS133

D4961 407 012 4406 DIODE 1SS133

D4962 407 012 4406 DIODE 1SS133

D4963 407 012 4406 DIODE 1SS133

D4964 407 012 4406 DIODE 1SS133

D4980

407 098 3300 DIODE RL153-BF-S2

D4981

407 098 3300 DIODE RL153-BF-S2

D4982

407 098 3300 DIODE RL153-BF-S2

D4983

407 098 3300 DIODE RL153-BF-S2

FCL41

645 006 4760 HOLDER,FUSE

645 031 7903 HOLDER,FUSE

FCL42

645 006 4760 HOLDER,FUSE

645 031 7903 HOLDER,FUSE

HS401 614 307 9866 HEAT SINK

IC410 409 384 3506 IC BA3314F

IC411 409 390 1107 IC LC75392

IC412

409 295 7402 IC TA8229K

L4781 645 006 9864 INDUCTOR,80U (AU)

or 645 041 3094 INDUCTOR,80U (AU)

L4881 645 006 9864 INDUCTOR,80U (AU)

or 645 041 3094 INDUCTOR,80U (AU)

L4902 645 031 5893 TRANS,OSC,85KHZ,O.S.C

LG401 645 006 4432 FIXER

PR495

645 014 2529 PROTECTOR,1.25A 125V

PR496 645 014 2536 PROTECTOR,1.5A 125V

Q4103 405 000 0508 TR DTA114ES

or 405 110 5400 TR KRA102M-A

Q4104 405 109 9204 TR KRC102M-A

or 405 000 3103 TR DTC114ES

Q4106 405 109 9204 TR KRC102M-A

or 405 000 3103 TR DTC114ES

Q4730 405 143 6504 TR KTA1267-GR

or 405 004 4601 TR 2SA608-F-SPA

or 405 004 5103 TR 2SA608-G-SPA

or 405 006 1806 TR 2SA933S-R

or 405 006 1905 TR 2SA933S-S

Q4751 405 151 4400 TR KTD1303

or 405 021 0204 TR 2SD1012-F-SPA

or 405 021 0600 TR 2SD1012-G-SPA

or 405 033 6706 TR 2SD1468S-R

or 405 033 6805 TR 2SD1468S-S

REF.NO. PART NO. DESCRIPTION

Q4830 405 004 5103 TR 2SA608-G-SPA

or 405 006 1806 TR 2SA933S-R

or 405 006 1905 TR 2SA933S-S

or 405 004 4601 TR 2SA608-F-SPA

or 405 143 6504 TR KTA1267-GR

Q4851 405 151 4400 TR KTD1303

or 405 021 0204 TR 2SD1012-F-SPA

or 405 021 0600 TR 2SD1012-G-SPA

or 405 033 6706 TR 2SD1468S-R

or 405 033 6805 TR 2SD1468S-S

Q4902 405 017 9709 TR 2SC3330-U

or 405 017 9600 TR 2SC3330-T

or 405 011 8609 TR 2SC1740S-S

or 405 143 8706 TR KTC3199-GR

or 405 011 8500 TR 2SC1740S-R

Q4903 405 011 8500 TR 2SC1740S-R

or 405 011 8609 TR 2SC1740S-S

or 405 143 8706 TR KTC3199-GR

or 405 017 9600 TR 2SC3330-T

or 405 017 9709 TR 2SC3330-U

Q4904 405 143 8706 TR KTC3199-GR

or 405 011 8500 TR 2SC1740S-R

or 405 011 8609 TR 2SC1740S-S

or 405 017 9600 TR 2SC3330-T

or 405 017 9709 TR 2SC3330-U

Q4951

405 138 6403 TR KTD2058Y

405 095 1602 TR 2SD2061-E

405 095 1701 TR 2SD2061-F

or 405 158 2102 TR KTC2026-Y

R4000 401 035 4108 MT-GLAZE 0.000 ZA 1/8W

R4001 401 035 4108 MT-GLAZE 0.000 ZA 1/8W

R4002 401 035 4108 MT-GLAZE 0.000 ZA 1/8W

R4003 401 035 4108 MT-GLAZE 0.000 ZA 1/8W

R4004 401 035 4108 MT-GLAZE 0.000 ZA 1/8W

R4104 401 037 5707 MT-GLAZE 100K JA 1/10W

R4105 401 037 5608 MT-GLAZE 10K JA 1/10W

R4106 401 037 5608 MT-GLAZE 10K JA 1/10W

R4107 401 038 6505 MT-GLAZE 47K JA 1/10W

R4703 401 038 7502 MT-GLAZE 56 JA 1/10W

R4704 401 038 5102 MT-GLAZE 3.9K JA 1/10W

R4705 401 037 9309 MT-GLAZE 18K JA 1/10W

R4708 401 037 9309 MT-GLAZE 18K JA 1/10W

R4709 401 037 7909 MT-GLAZE 1.5K JA 1/10W

R4710 401 038 5102 MT-GLAZE 3.9K JA 1/10W

R4716 401 037 5400 MT-GLAZE 1K JA 1/10W

R4717 401 037 8005 MT-GLAZE 15K JA 1/10W

R4718 401 037 7800 MT-GLAZE 150 JA 1/10W

R4730 401 038 0800 MT-GLAZE 22K JA 1/10W

R4731 401 037 6902 MT-GLAZE 120K JA 1/10W

R4732 401 038 9308 MT-GLAZE 68K JA 1/10W (AU)

R4732 401 038 3702 MT-GLAZE 33K JA 1/10W (PA)

R4733 401 038 3603 MT-GLAZE 3.3K JA 1/10W

R4734 401 038 6406 MT-GLAZE 4.7K JA 1/10W

R4735 401 038 5102 MT-GLAZE 3.9K JA 1/10W

R4736 401 038 6505 MT-GLAZE 47K JA 1/10W

R4737 401 038 9209 MT-GLAZE 6.8K JA 1/10W

R4738 401 037 5400 MT-GLAZE 1K JA 1/10W

R4739 401 038 6505 MT-GLAZE 47K JA 1/10W

R4740 401 038 0800 MT-GLAZE 22K JA 1/10W

R4741 401 038 2200 MT-GLAZE 27K JA 1/10W

R4742 401 037 5608 MT-GLAZE 10K JA 1/10W

R4743 401 037 5707 MT-GLAZE 100K JA 1/10W

R4745 401 037 5608 MT-GLAZE 10K JA 1/10W

R4746 401 039 0502 MT-GLAZE 82K JA 1/10W

R4747 401 038 9308 MT-GLAZE 68K JA 1/10W

R4748 401 038 0800 MT-GLAZE 22K JA 1/10W

R4749 401 038 0800 MT-GLAZE 22K JA 1/10W
