- 7 -

PARTS LIST

REF.NO. PART NO. DESCRIPTION

R4750 401 038 0800 MT-GLAZE 22K JA 1/10W

R4751 401 038 0800 MT-GLAZE 22K JA 1/10W

R4752

402 071 1304 FUSIBLE RES 2.2 JA 1/4W

R4753 401 037 9408 MT-GLAZE 180K JA 1/10W

R4756 401 038 6406 MT-GLAZE 4.7K JA 1/10W

R4760 401 037 5608 MT-GLAZE 10K JA 1/10W

R4761 401 037 5400 MT-GLAZE 1K JA 1/10W

R4770 401 038 6505 MT-GLAZE 47K JA 1/10W

R4781 401 037 7800 MT-GLAZE 150 JA 1/10W

R4803 401 038 7502 MT-GLAZE 56 JA 1/10W

R4804 401 038 5102 MT-GLAZE 3.9K JA 1/10W

R4805 401 037 9309 MT-GLAZE 18K JA 1/10W

R4808 401 037 9309 MT-GLAZE 18K JA 1/10W

R4809 401 037 7909 MT-GLAZE 1.5K JA 1/10W

R4810 401 038 5102 MT-GLAZE 3.9K JA 1/10W

R4816 401 037 5400 MT-GLAZE 1K JA 1/10W

R4817 401 037 8005 MT-GLAZE 15K JA 1/10W

R4818 401 037 7800 MT-GLAZE 150 JA 1/10W

R4830 401 038 0800 MT-GLAZE 22K JA 1/10W

R4831 401 037 6902 MT-GLAZE 120K JA 1/10W

R4832 401 038 9308 MT-GLAZE 68K JA 1/10W (AU)

R4832 401 038 3702 MT-GLAZE 33K JA 1/10W (PA)

R4833 401 038 3603 MT-GLAZE 3.3K JA 1/10W

R4834 401 038 6406 MT-GLAZE 4.7K JA 1/10W

R4835 401 038 5102 MT-GLAZE 3.9K JA 1/10W

R4836 401 038 6505 MT-GLAZE 47K JA 1/10W

R4837 401 038 9209 MT-GLAZE 6.8K JA 1/10W

R4838 401 037 5400 MT-GLAZE 1K JA 1/10W

R4839 401 038 6505 MT-GLAZE 47K JA 1/10W

R4840 401 038 0800 MT-GLAZE 22K JA 1/10W

R4841 401 038 2200 MT-GLAZE 27K JA 1/10W

R4842 401 037 5608 MT-GLAZE 10K JA 1/10W

R4843 401 037 5707 MT-GLAZE 100K JA 1/10W

R4845 401 037 5608 MT-GLAZE 10K JA 1/10W

R4846 401 039 0502 MT-GLAZE 82K JA 1/10W

R4847 401 038 9308 MT-GLAZE 68K JA 1/10W

R4848 401 038 0800 MT-GLAZE 22K JA 1/10W

R4849 401 038 0800 MT-GLAZE 22K JA 1/10W

R4850 401 038 0800 MT-GLAZE 22K JA 1/10W

R4851 401 038 0800 MT-GLAZE 22K JA 1/10W

R4852

402 071 1304 FUSIBLE RES 2.2 JA 1/4W

R4853 401 037 9408 MT-GLAZE 180K JA 1/10W

R4856 401 038 6406 MT-GLAZE 4.7K JA 1/10W

R4860 401 037 5608 MT-GLAZE 10K JA 1/10W

R4861 401 037 5400 MT-GLAZE 1K JA 1/10W

R4870 401 038 6505 MT-GLAZE 47K JA 1/10W

R4881 401 037 7800 MT-GLAZE 150 JA 1/10W

R4890 401 039 0205 MT-GLAZE 82 JA 1/10W

R4901 401 038 7403 MT-GLAZE 510K JA 1/10W

R4905 401 037 5202 MT-GLAZE 100 JA 1/10W

R4910 401 037 5608 MT-GLAZE 10K JA 1/10W

R4911 401 037 6506 MT-GLAZE 12 JA 1/10W

R4912 401 038 3504 MT-GLAZE 330 JA 1/10W

R4914 401 038 2101 MT-GLAZE 2.7K JA 1/10W

R4938 401 037 5608 MT-GLAZE 10K JA 1/10W

R4941

402 081 0205 FUSIBLE RES 27 JA 1/4W

R4948 401 038 0701 MT-GLAZE 2.2K JA 1/10W

R4949 401 038 0701 MT-GLAZE 2.2K JA 1/10W

R4961 401 037 5608 MT-GLAZE 10K JA 1/10W

R4962 401 037 5400 MT-GLAZE 1K JA 1/10W

R4971 401 037 5202 MT-GLAZE 100 JA 1/10W

R4972 401 037 5400 MT-GLAZE 1K JA 1/10W

R4991 401 037 5608 MT-GLAZE 10K JA 1/10W

S4901

645 009 8871 SWITCH,PUSH 2P-2T,POWERSW

S4905 645 040 8137 SWITCH,SLIDE 2P-2TX1,BEAT CCL

S4950 645 038 7586 SWITCH,PUSH,R/PSW

SA401 411 021 6405 SCR S-TPG BIN 3X8

SA402 411 021 6405 SCR S-TPG BIN 3X8

614 125 0236 CUSHION,FOR W207

FRONT P.W.BOARD ASSY

REF.NO. PART NO. DESCRIPTION

72 614 310 4100 ASSY,PWB,FRONT (Only Initial)

BR601 614 307 2164 HOLDER,LCD

C6200 403 259 0508 NP-ELECT 1U M 50V

CN601 645 012 5164 SOCKET,FPC 12P

CN602 614 016 8464 PLUG

CN603 645 012 5508 SOCKET,FPC 17P,FRONT-TU

D6901 407 012 4406 DIODE 1SS133

D6902 407 012 4406 DIODE 1SS133

IC601 409 475 7505 IC LC72336-9921

L6900 645 001 4550 INDUCTOR,10U K

or 645 031 7835 INDUCTOR,10U K

LCD60 645 038 7562 LCD

LS601 614 309 4180 DEC,SHEET,LCD_SHEET

Q6200 405 143 8706 TR KTC3199-GR

or 405 011 8500 TR 2SC1740S-R

or 405 011 8609 TR 2SC1740S-S

or 405 017 9600 TR 2SC3330-T

or 405 017 9709 TR 2SC3330-U

Q6201 405 143 8706 TR KTC3199-GR

or 405 011 8500 TR 2SC1740S-R

or 405 011 8609 TR 2SC1740S-S

or 405 017 9600 TR 2SC3330-T

or 405 017 9709 TR 2SC3330-U

R6001 401 038 7601 MT-GLAZE 560 JA 1/10W

R6002 401 038 9001 MT-GLAZE 680 JA 1/10W

R6003 401 039 0304 MT-GLAZE 820 JA 1/10W

R6004 401 037 6704 MT-GLAZE 1.2K JA 1/10W

R6005 401 038 7601 MT-GLAZE 560 JA 1/10W

R6006 401 038 9001 MT-GLAZE 680 JA 1/10W

R6007 401 039 0304 MT-GLAZE 820 JA 1/10W

R6008 401 037 6704 MT-GLAZE 1.2K JA 1/10W

R6009 401 037 9309 MT-GLAZE 18K JA 1/10W

R6010 401 037 5608 MT-GLAZE 10K JA 1/10W

R6011 401 037 5608 MT-GLAZE 10K JA 1/10W

R6012 401 037 5608 MT-GLAZE 10K JA 1/10W

R6100 401 037 5707 MT-GLAZE 100K JA 1/10W

R6101 401 037 5707 MT-GLAZE 100K JA 1/10W

R6102 401 037 5707 MT-GLAZE 100K JA 1/10W

R6103 401 037 5707 MT-GLAZE 100K JA 1/10W

R6104 401 037 5608 MT-GLAZE 10K JA 1/10W

R6105 401 037 5608 MT-GLAZE 10K JA 1/10W

R6106 401 037 5608 MT-GLAZE 10K JA 1/10W

R6107 401 038 6406 MT-GLAZE 4.7K JA 1/10W

R6108 401 038 6406 MT-GLAZE 4.7K JA 1/10W

R6109 401 038 6505 MT-GLAZE 47K JA 1/10W

R6110 401 037 5707 MT-GLAZE 100K JA 1/10W

R6111 401 038 6505 MT-GLAZE 47K JA 1/10W

R6112 401 037 5608 MT-GLAZE 10K JA 1/10W

R6113 401 037 5608 MT-GLAZE 10K JA 1/10W

R6120 401 037 8005 MT-GLAZE 15K JA 1/10W

R6121 401 038 0800 MT-GLAZE 22K JA 1/10W

R6122 401 039 0403 MT-GLAZE 8.2K JA 1/10W

R6123 401 038 0800 MT-GLAZE 22K JA 1/10W

R6200 401 038 0701 MT-GLAZE 2.2K JA 1/10W

R6201 401 038 2101 MT-GLAZE 2.7K JA 1/10W

R6300 401 035 4108 MT-GLAZE 0.000 ZA 1/8W

R6301 401 035 4108 MT-GLAZE 0.000 ZA 1/8W

R6302 401 035 4108 MT-GLAZE 0.000 ZA 1/8W

R6303 401 035 4108 MT-GLAZE 0.000 ZA 1/8W

R6304 401 035 4108 MT-GLAZE 0.000 ZA 1/8W

R6305 401 035 4108 MT-GLAZE 0.000 ZA 1/8W

R6306 401 035 4108 MT-GLAZE 0.000 ZA 1/8W

R6307 401 035 4108 MT-GLAZE 0.000 ZA 1/8W

R6308 401 035 4108 MT-GLAZE 0.000 ZA 1/8W

R6309 401 035 4108 MT-GLAZE 0.000 ZA 1/8W

R6310 401 035 4108 MT-GLAZE 0.000 ZA 1/8W

R6311 401 035 4108 MT-GLAZE 0.000 ZA 1/8W
