- 8 -

PARTS LIST

CD P.W.BOARD ASSY

REF.NO. PART NO. DESCRIPTION

73 614 307 8982 ASSY,PWB,CD (Only Initial)

CN111 645 040 0513 SOCKET,FPC 15P

or 645 026 2463 SOCKET,FFC 15P

CN113 645 005 8127 PLUG,6P,BASEMECHA

CN122 645 005 8134 PLUG,8P

D1402 407 099 5204 ZENER DIODE MTZJ5.1B

D1403 407 012 4406 DIODE 1SS133

D1404 407 012 4406 DIODE 1SS133

D1410

407 098 3300 DIODE RL153-BF-S2

IC101 409 396 8100 IC LA9241ML

IC102 409 435 2106 IC LC78622NE

IC103

409 372 9602 IC LA6541(until M0403001 for AU,

M0402001 for PA)

IC103

409 486 8706 IC MM1469XH (M0403001 onward for

AU, M0402001 onward for PA)

L1451 645 001 4550 INDUCTOR,10U K

or 645 031 7835 INDUCTOR,10U K

PR140

645 014 2499 PROTECTOR,0.4A 125V

Q1301 405 008 7103 TR 2SB808-G-SPA

or 405 008 6809 TR 2SB808-F-SPA

or 405 151 4509 TR KTA1270-Y

or 405 151 4608 TR KTA1270-O

REF.NO. PART NO. DESCRIPTION

Q1401

405 009 5306 TR 2SB927-T

405 009 5207 TR 2SB927-S

405 158 2201 TR KTA1282

405 141 3604 TR KTA1273-Y

R1301 401 037 5400 MT-GLAZE 1K JA 1/10W

R1302 401 037 5103 MT-GLAZE 10 JA 1/10W

R1303 401 037 5707 MT-GLAZE 100K JA 1/10W

R1304 401 038 9209 MT-GLAZE 6.8K JA 1/10W

R1305 401 038 0701 MT-GLAZE 2.2K JA 1/10W

R1308 401 038 2200 MT-GLAZE 27K JA 1/10W

R1309 401 038 3504 MT-GLAZE 330 JA 1/10W

R1310 401 037 8005 MT-GLAZE 15K JA 1/10W

R1311 401 037 5707 MT-GLAZE 100K JA 1/10W

R1312 401 038 9209 MT-GLAZE 6.8K JA 1/10W

R1313 401 038 0800 MT-GLAZE 22K JA 1/10W

R1314 401 038 0800 MT-GLAZE 22K JA 1/10W

R1315 401 037 8005 MT-GLAZE 15K JA 1/10W

R1317 401 038 9308 MT-GLAZE 68K JA 1/10W

R1318 401 037 7909 MT-GLAZE 1.5K JA 1/10W

R1320 401 039 0403 MT-GLAZE 8.2K JA 1/10W

R1324 401 038 3702 MT-GLAZE 33K JA 1/10W

R1325 401 038 7809 MT-GLAZE 56K JA 1/10W

R1326 401 037 5400 MT-GLAZE 1K JA 1/10W

R1327 401 038 7809 MT-GLAZE 56K JA 1/10W

R1328 401 038 9209 MT-GLAZE 6.8K JA 1/10W

R1329 401 037 5608 MT-GLAZE 10K JA 1/10W

R1330 401 038 0909 MT-GLAZE 220K JA 1/10W

R1331 401 038 0909 MT-GLAZE 220K JA 1/10W

R1332 401 037 8005 MT-GLAZE 15K JA 1/10W

R1333 401 037 6803 MT-GLAZE 12K JA 1/10W

R1334 401 037 5400 MT-GLAZE 1K JA 1/10W

R1335 401 037 5608 MT-GLAZE 10K JA 1/10W

R1336 401 038 3504 MT-GLAZE 330 JA 1/10W

R1337 401 038 9209 MT-GLAZE 6.8K JA 1/10W

R1343 401 037 5707 MT-GLAZE 100K JA 1/10W

R1453 401 038 2101 MT-GLAZE 2.7K JA 1/10W

R1454 401 038 9001 MT-GLAZE 680 JA 1/10W

R1455 401 038 9308 MT-GLAZE 68K JA 1/10W

R1456 401 037 6704 MT-GLAZE 1.2K JA 1/10W

R1462 401 038 7601 MT-GLAZE 560 JA 1/10W

R1463 401 038 7601 MT-GLAZE 560 JA 1/10W

R1464 401 037 5400 MT-GLAZE 1K JA 1/10W

R1465 401 038 7601 MT-GLAZE 560 JA 1/10W

R1472 401 038 6406 MT-GLAZE 4.7K JA 1/10W

R1473 401 037 5707 MT-GLAZE 100K JA 1/10W

R1475 401 038 7601 MT-GLAZE 560 JA 1/10W

R1480 401 038 7601 MT-GLAZE 560 JA 1/10W

R1498 401 037 5202 MT-GLAZE 100 JA 1/10W

R1499 401 037 5202 MT-GLAZE 100 JA 1/10W

R1501 401 038 9209 MT-GLAZE 6.8K JA 1/10W

R1502 401 037 5608 MT-GLAZE 10K JA 1/10W

R1503 401 038 9209 MT-GLAZE 6.8K JA 1/10W

R1771 401 037 5400 MT-GLAZE 1K JA 1/10W

R1773 401 037 5707 MT-GLAZE 100K JA 1/10W

R1781 401 037 5400 MT-GLAZE 1K JA 1/10W

R1783 401 037 5707 MT-GLAZE 100K JA 1/10W

X1451 614 231 2667 RESONATOR

TUNER P.W.BOARD ASSY

REF.NO. PART NO. DESCRIPTION

74 614 310 4902 ASSY,PWB,TUNER (AU)(Only Initial)

74 614 310 4926 ASSY,PWB,TUNER (PA)(Only Initial)

CN201 645 038 7715 TERMINAL

or 614 025 4703 TERMINAL

CN202 645 012 5218 SOCKET,FPC 17P

CN203 614 221 8273 TERMINAL

REF.NO. PART NO. DESCRIPTION

R6501 401 037 5400 MT-GLAZE 1K JA 1/10W

R6502 401 037 5400 MT-GLAZE 1K JA 1/10W

R6905 401 037 5202 MT-GLAZE 100 JA 1/10W

R6906 401 038 6307 MT-GLAZE 470 JA 1/10W

R6907 401 038 6505 MT-GLAZE 47K JA 1/10W

S6000 614 220 5471 SWITCH,TACT
