- 9 -
PARTS LIST
REF.NO. PART NO. DESCRIPTION
CT211 645 032 5663 TRIMMER,7PF
D2002 407 157 8109 VARACTOR DI SVC211-B
D2003 407 157 8109 VARACTOR DI SVC211-B
D2004 407 012 4406 DIODE 1SS133
D2005 407 012 4406 DIODE 1SS133
D2006 407 012 4406 DIODE 1SS133
D2101 407 012 4406 DIODE 1SS133
D2102 407 105 1305 VARACTOR DI SVC342L-V
or 407 105 1602 VARACTOR DI SVC342M-V
D2104 407 099 5303 ZENER DIODE MTZJ5.6B
IC201 409 016 0200 IC LA1186N-AUDIO
IC211 409 474 3201 IC LA1844ML
L2001 645 040 2753 INDUCTOR,AIR ---
L2002 645 040 2746 COIL,AIR ---
L2003 645 002 1534 INDUCTOR,8.2U K
or 645 031 7859 INDUCTOR,8.2U K
L2005 645 002 1459 INDUCTOR,22U K
L2006 645 002 1459 INDUCTOR,22U K
L2007 645 002 1459 INDUCTOR,22U K
L2010 645 040 2760 INDUCTOR,AIR ---
L2011 645 041 1328 INDUCTOR,AIR ---
L2204 645 037 2377 TRANS,ANT,796KHZ
L2205 645 040 2739 TRANS,OSC,796KHZ
LUG01 614 129 9082 LUG,W205 (AU)
Q2001 405 151 4806 TR KTC3195-O
or 405 151 4301 TR KTC3195-Y
Q2002 405 151 4806 TR KTC3195-O
or 405 151 4301 TR KTC3195-Y
Q2003 405 143 8706 TR KTC3199-GR
or 405 011 8500 TR 2SC1740S-R
or 405 011 8609 TR 2SC1740S-S
or 405 017 9600 TR 2SC3330-T
or 405 017 9709 TR 2SC3330-U
Q2101 405 151 5209 TR KRA107M
Q2102 405 143 0007 TR KRC107M
Q2110 405 143 0007 TR KRC107M
Q2111 405 151 4806 TR KTC3195-O
or 405 151 4301 TR KTC3195-Y
Q2201 405 151 5209 TR KRA107M
R2001 401 038 3801 MT-GLAZE 330K JA 1/10W
R2002 401 037 5608 MT-GLAZE 10K JA 1/10W
R2003 401 037 9002 MT-GLAZE 18 JA 1/10W
R2004 401 037 5608 MT-GLAZE 10K JA 1/10W
R2005 401 038 0503 MT-GLAZE 22 JA 1/10W
R2006 401 038 7601 MT-GLAZE 560 JA 1/10W
R2007 401 038 7908 MT-GLAZE 560K JA 1/10W
R2008 401 038 0602 MT-GLAZE 220 JA 1/10W
R2009 401 038 3504 MT-GLAZE 330 JA 1/10W
R2010 401 037 5202 MT-GLAZE 100 JA 1/10W
R2011 401 037 6902 MT-GLAZE 120K JA 1/10W
R2014 401 037 5707 MT-GLAZE 100K JA 1/10W
R2101 401 038 5102 MT-GLAZE 3.9K JA 1/10W
R2104 401 037 5608 MT-GLAZE 10K JA 1/10W
R2105 401 037 5608 MT-GLAZE 10K JA 1/10W
R2106 401 038 2101 MT-GLAZE 2.7K JA 1/10W
R2107 401 038 9209 MT-GLAZE 6.8K JA 1/10W
R2113 401 037 5608 MT-GLAZE 10K JA 1/10W
R2117 401 039 0601 MT-GLAZE 820K JA 1/10W
R2119 401 038 0800 MT-GLAZE 22K JA 1/10W
R2126 401 037 6902 MT-GLAZE 120K JA 1/10W
R2127 401 038 6406 MT-GLAZE 4.7K JA 1/10W
R2128 401 038 3801 MT-GLAZE 330K JA 1/10W
R2129 401 038 0800 MT-GLAZE 22K JA 1/10W
R2131 401 038 7809 MT-GLAZE 56K JA 1/10W
LED P.W.BOARD ASSY
REF.NO. PART NO. DESCRIPTION
75 614 307 9002 ASSY,PWB,LED (Only Initial)
D6600 408 037 0503 LED SLP-3118C-51HAB-T1
D6601 408 037 0503 LED SLP-3118C-51HAB-T1
D6602 408 037 0503 LED SLP-3118C-51HAB-T1
D6603 408 037 0503 LED SLP-3118C-51HAB-T1
D6604 408 037 0503 LED SLP-3118C-51HAB-T1
D6605 408 037 0503 LED SLP-3118C-51HAB-T1
R6600 401 037 7800 MT-GLAZE 150 JA 1/10W
R6601 401 037 7800 MT-GLAZE 150 JA 1/10W
PT P.W.BOARD ASSY
REF.NO. PART NO. DESCRIPTION
76 614 307 9019 ASSY,PWB,PT (AU)(Only Initial)
76 614 310 6807 ASSY,PWB,PT (PA)(Only Initial)
CN450 614 020 1215 SOCKET,2P
CN451 614 017 8203 TERMINAL BOARD (AU)
CN451 614 017 6964 TERMINAL BOARD (PA)
CN452 614 017 8203 TERMINAL BOARD (AU)
CN452 614 017 6964 TERMINAL BOARD (PA)
CN453 614 309 8447 ASSY,WIRE
L4591
!
!!
645 038 6053 INDUCTOR,181U (AU)
or
!
!!
645 017 8061 INDUCTOR,181M (AU)
or
!
!!
645 041 3087 INDUCTOR,180M (AU)
S4970 614 226 3624 SWITCH (PA)
REF.NO. PART NO. DESCRIPTION
R2201 401 037 5202 MT-GLAZE 100 JA 1/10W
R2205 401 038 9308 MT-GLAZE 68K JA 1/10W
R2206 401 038 0701 MT-GLAZE 2.2K JA 1/10W
R2210 401 037 5400 MT-GLAZE 1K JA 1/10W
R2301 401 038 9308 MT-GLAZE 68K JA 1/10W
R2302 401 038 0800 MT-GLAZE 22K JA 1/10W
R2303 401 037 9309 MT-GLAZE 18K JA 1/10W
R2701 401 037 7909 MT-GLAZE 1.5K JA 1/10W
R2801 401 037 7909 MT-GLAZE 1.5K JA 1/10W
R2900 401 035 4108 MT-GLAZE 0.000 ZA 1/8W
S2001 645 023 5795 SWITCH,LEVER
SH201 614 256 3052 SHIELD
SH203 614 311 3867 SHIELD,EMC FOR TU PWB (AU)
T2002 645 040 9981 TRANS,IF 10.7MHZ
XF211 645 010 7665 CERAMIC FILTER 10.70MHZ
XF212 645 010 7665 CERAMIC FILTER 10.70MHZ
XF215 645 023 0134 CERAMIC FILTER 450KHZ
To Next Page
