Sanyo DP23625 Service Manual

— 21 —
Schematic
Location
Part No.
Description
Q3031(Cont)405 163 1602 TR 2SC2812N-L6-TB
405 163 1701 TR 2SC2812N-L7-TB
405 173 9803 TR 2SC3928A1R
405 173 9902 TR 2SC3928A1S
Q3032 405 014 4509 TR 2SC2412K-T-96-R
405 014 4608 TR 2SC2412K-T-96-S
405 015 8724 TR 2SC2812-L6-TB
405 015 8922 TR 2SC2812-L7-TB
405 163 1602 TR 2SC2812N-L6-TB
405 163 1701 TR 2SC2812N-L7-TB
405 173 9803 TR 2SC3928A1R
405 173 9902 TR 2SC3928A1S
Q7289 405 014 4509 TR 2SC2412K-T-96-R
405 014 4608 TR 2SC2412K-T-96-S
405 015 8724 TR 2SC2812-L6-TB
405 015 8922 TR 2SC2812-L7-TB
405 163 1602 TR 2SC2812N-L6-TB
405 163 1701 TR 2SC2812N-L7-TB
405 173 9803 TR 2SC3928A1R
405 173 9902 TR 2SC3928A1S
Q8061 405 014 4509 TR 2SC2412K-T-96-R
405 014 4608 TR 2SC2412K-T-96-S
405 015 8724 TR 2SC2812-L6-TB
405 015 8922 TR 2SC2812-L7-TB
405 163 1602 TR 2SC2812N-L6-TB
405 163 1701 TR 2SC2812N-L7-TB
405 173 9803 TR 2SC3928A1R
405 173 9902 TR 2SC3928A1S
RB2001 645 037 0663 R-NETWORK 22X4 0.063W
645 021 4943 R-NETWORK 22X4 1/16W
RB2002 645 037 0663 R-NETWORK 22X4 0.063W
645 021 4943 R-NETWORK 22X4 1/16W
RB2003 645 037 0663 R-NETWORK 22X4 0.063W
645 021 4943 R-NETWORK 22X4 1/16W
RB2004 645 037 0663 R-NETWORK 22X4 0.063W
645 021 4943 R-NETWORK 22X4 1/16W
RB7201 645 037 0663 R-NETWORK 22X4 0.063W
645 021 4943 R-NETWORK 22X4 1/16W
RB7202 645 037 0663 R-NETWORK 22X4 0.063W
645 021 4943 R-NETWORK 22X4 1/16W
RB7203 645 037 0663 R-NETWORK 22X4 0.063W
645 021 4943 R-NETWORK 22X4 1/16W
RB7204 645 037 0663 R-NETWORK 22X4 0.063W
645 021 4943 R-NETWORK 22X4 1/16W
R001 401 256 7605 MT-GLAZE 3.9K JA 1/10W
R002 401 152 3206 MT-GLAZE 330 JA 1/10W
R004 401 256 6301 MT-GLAZE 47K JA 1/10W
R021 401 150 6209 MT-GLAZE 1K JA 1/10W
R022 401 256 7605 MT-GLAZE 3.9K JA 1/10W
R023 401 150 6209 MT-GLAZE 1K JA 1/10W
R024 401 256 7605 MT-GLAZE 3.9K JA 1/10W
R026 401 184 2000 MT-GLAZE 2.2 JA 1/2W
R027 401 184 2000 MT-GLAZE 2.2 JA 1/2W
R028 401 150 6001 MT-GLAZE 0.000 ZA 1/10W
R029 401 150 6001 MT-GLAZE 0.000 ZA 1/10W
R101 401 255 6500 MT-GLAZE 100 JA 1/10W
R102 401 255 6500 MT-GLAZE 100 JA 1/10W
R103 401 255 6500 MT-GLAZE 100 JA 1/10W
R104 401 255 6500 MT-GLAZE 100 JA 1/10W
R111 401 162 3609 MT-GLAZE 470 JA 1/10W
R112 401 150 6001 MT-GLAZE 0.000 ZA 1/10W
R113 401 256 4109 MT-GLAZE 56 JA 1/10W
R121 401 150 6001 MT-GLAZE 0.000 ZA 1/10W
R123 401 150 6001 MT-GLAZE 0.000 ZA 1/10W
R127 401 150 6001 MT-GLAZE 0.000 ZA 1/10W
R129 401 150 6001 MT-GLAZE 0.000 ZA 1/10W
R131 401 150 6001 MT-GLAZE 0.000 ZA 1/10W
R133 401 150 6001 MT-GLAZE 0.000 ZA 1/10W
R137 401 150 6001 MT-GLAZE 0.000 ZA 1/10W
R139 401 150 6001 MT-GLAZE 0.000 ZA 1/10W
R606 401 256 5601 MT-GLAZE 47 JA 1/10W
R607 401 255 8702 MT-GLAZE 22 JA 1/10W
R608 401 256 1702 MT-GLAZE 33K JA 1/10W
R620 401 150 6001 MT-GLAZE 0.000 ZA 1/10W
R622 401 035 4108 MT-GLAZE 0.000 ZA 1/8W
R626 401 035 4108 MT-GLAZE 0.000 ZA 1/8W
R647 401 264 2807 MT-GLAZE 1.2K FA 1/10W
R648 401 264 1800 MT-GLAZE 1K FA 1/10W
R649 401 264 7505 MT-GLAZE 2.7K FA 1/10W
R651 401 035 4108 MT-GLAZE 0.000 ZA 1/8W
R656 401 162 3005 MT-GLAZE 22K JA 1/10W
R657 401 162 3005 MT-GLAZE 22K JA 1/10W
R671 401 162 3005 MT-GLAZE 22K JA 1/10W
R672 401 162 3005 MT-GLAZE 22K JA 1/10W
Schematic
Location
Part No.
Description
Tolerance Symbols:
A...0.05% B...0.1% C...25%
D...0.5% F...1% G...2%
J...5% K...10% M...20%
P...+5 -15%
Rated Value, ohms:
K...1,000 M...1,000,000
Material:
CARBON .............
MT-FILM ..............
OXIDE-MT ...........
SOLID ..................
MT-GLAZE ...........
WIRE WOUND .....
CERAMIC RES ....
FUSIBLE RES .....
Performance Symbols:
A...General B...Non-flammable
Z...Low noise
Other... Temperature coefficient
Rated Wattage
CARBON 4.7K J A 1/4W
Read description of the Resistor as follows:
NOTES:
(Example)
Carbon
Metal Film
Oxide Metal Film
Composition
Metal Glaze
Wire Wound
Ceramic
Fusible
