CAPACITOR AND RESISTOR CODE CHART

CAPACITOR (Example)

500 C K 1500 B D ........................... ±0.5pF

T ............................ +50% –10%

J ............................ ±5%

K ........................... ±10%

M ........................... ±20%

N ........................... ±30%

Characteristics P ........................... +100% –0%

Value code Z ........................... +80% –20%

Tolerance code C ........................... ±0.25pF

Material code C ........................... Ceramic

Voltage rating E ........................... Electrolytic

F ........................... Polyester

N ........................... Polypropylene

T ............................ Tantalum

K ........................... Ceramic

H ........................... MT-Composite

P ........................... NP. Electrolytic

M ........................... MT-Polypropylene

RESISTOR (Example)

6 Y K 4.7 D ........................... ±0.5%

F ........................... ±1%

G ........................... ±2%

J ............................ ±5%

Value code K ........................... ±10%

Tolerance code M ........................... ±20%

Material code F ............................ Fusible

Wattage rating N ........................... Metalized Carbon

S ........................... Oxide Metalized

Y ........................... Wire Wound

C ........................... Solid

D ........................... Carbon Film

W .......................... Wire Wound
