Sanyo DP23625 User Manual

(
AV3
TUNER
R
R
VHF
U
HF
C
ATV
Y
Pb
Pr
(
)
R
L
R
L
A
U
D
IO
O
U
T
P
U
T
R
L
Y
Pb
Pr
VIDEO OUT SELECT
COPONENT
S
Y
C
B C R
AUDIO OUT
RL
VIDEO OUT
COMPONENT VIDEO OUT
S-VIDEO OUT
DIGITAL
OUT
OPT.
CONNECTING A DVD PLAYER OR
OTHER EQUIPMENT
Switch off TV and external equipment before
connecting cables. (Cables are not supplied.)
1
Connect a DVD Player or other equipment’s
Component Video Out to the TV Component
Video In (Y-Pb-Pr) Jacks.
2
Connect the DVD Player’s Audio Out to the
TV Component L/R Jacks.
3
Press POWER to turn on the TV. Turn on
external equipment also.
4
Press the INPUT key to select COMPO-
NENT3.
DVD Player
USING THE COMPONENT AUDIO VIDEO INPUT JACKS
TV Back
1
 A solid Blue screen with COMPONENT3 displayed
means that the Video mode is selected, but no signal is
being detected at the Component jacks. Check connec-
tion, and turn on external equipment.
 Press the INPUT key after connecting cables to access
the A/V Inputs. There is NO need to tune to a blank
channel.
What you will need for
connections:
1
Component Video
Cable – 1
2 Audio Cable – 1
8
Need help? Visit our Web site at www.sanyoctv.com or Call 1-800-877-5032
2
USING THE AUDIO OUTPUT JACKS
TUN
ER
VHF
UH
F
CA
T
V
Pb
Pr
R
L
R
L
A
UD
IO
O
U
T
P
UT
R
L
CONNECTING AUDIO OUT JACKS
TO A STEREO AMPLIFIER
Switch off TV and external equipment before
connecting cables. (Cables are not supplied.)
1
Connect the TV Audio Out (R/L) to the Stereo
Amplifier In (R/L).
2
Press POWER to turn on the TV. Turn on
external equipment also.
Note: DO NOT connect external speakers directly
to the TV.
Stereo
Amplifier
What you will
need for
connections:
1
Audio Cable – 1
TV Back
Remote Control
1 2 3
RESETINPUT
POWER
123
3
4
1
