– 11 –
Schematic
Location
Part No.
Description
Schematic
Location
Part No.
Description
INTEGRATED CIRCUITS
IC001 C1AB00003628 IC STA333W13TR
IC5500 C1AB00003859 IC ZR39748BGCG-A3
IC5700 C3ABSY000102 IC H5PS5162GFR-S6C
IC5750 QXXAAJQ1300— IC S25FL064P0XMFI0 N8LJ
IC5900 C0EBY0001079 IC XC6118N28AMR-G
IC6530 C0JBAA000345 “IC TC7SET08FU(T5L,JF)”
C0JBAA000502 “IC TC7SET08FU(5L,JF,T”
C0JBAA000505 IC 74AHCT1G08GW
IC6560 C0JBAA000345 “IC TC7SET08FU(T5L,JF)”
C0JBAA000502 “IC TC7SET08FU(5L,JF,T”
C0JBAA000505 IC 74AHCT1G08GW
IC6600 C0DBZYY00485 IC NCP380HSN05AAT1G
IC6700 C0CBAYG00009 IC LM1117S-ADJ
IC6720 C0DBAYY01122 IC BD9328EFJ-E2
IC6750 C0DBGYY02242 IC AP2128K-ADJTRG1
COILS
L001 G1C220MA0445 “INDUCTOR ,22UH”
L002 G1C220MA0445 “INDUCTOR ,22UH”
L003 G1C220MA0445 “INDUCTOR ,22UH”
L009 J0JCC0000371 “INDUCTOR , 120 OHM”
L011 J0JYC0000381 “INDUCTOR , 220 OHM”
L012 J0JYC0000381 “INDUCTOR , 220 OHM”
L013 G1C220MA0445 “INDUCTOR ,22UH”
L017 J0JCC0000371 “INDUCTOR , 120 OHM”
L5500 J0JCC0000371 “INDUCTOR , 120 OHM”
L5501 J0JCC0000371 “INDUCTOR , 120 OHM”
L5502 J0JCC0000371 “INDUCTOR , 120 OHM”
L5503 J0JYC0000381 “INDUCTOR , 220 OHM”
L5504 J0JYC0000381 “INDUCTOR , 220 OHM”
L5505 J0JCC0000371 “INDUCTOR , 120 OHM”
L5506 J0JCC0000371 “INDUCTOR , 120 OHM”
L5507 J0JCC0000371 “INDUCTOR , 120 OHM”
L5508 J0JCC0000371 “INDUCTOR , 120 OHM”
L5509 J0JCC0000371 “INDUCTOR , 120 OHM”
L5510 J0JCC0000371 “INDUCTOR , 120 OHM”
L5511 J0JCC0000371 “INDUCTOR , 120 OHM”
L5512 D0GB750JA041 MT-GLAZE 75 JA 1/10W
D0GB750JA072 MT-GLAZE 75 JA 1/10W
D0GB750JA089 MT-GLAZE 75 JA 1/10W
L5513 J0JCC0000371 “INDUCTOR , 120 OHM”
L5514 J0JCC0000371 “INDUCTOR , 120 OHM”
L5515 J0JCC0000371 “INDUCTOR , 120 OHM”
L5516 G1CR22JA0135 “INDUCTOR ,0.22UH”
L6301 D0GDR00JA072 MT-GLAZE 0.000 ZA 1/10W
D0GDR00Z0002 MT-GLAZE 0.000 ZA 1/10W
L6308 D0GDR00JA072 MT-GLAZE 0.000 ZA 1/10W
D0GDR00Z0002 MT-GLAZE 0.000 ZA 1/10W
L6313 D1HYR004A012 R-NETWORK 0X4 0.063W
L6314 D1HYR004A012 R-NETWORK 0X4 0.063W
L6315 D1HYR004A012 R-NETWORK 0X4 0.063W
L6720 G1C220MA0445 “INDUCTOR ,22UH”
L6721 D0GDR00JA072 MT-GLAZE 0.000 ZA 1/10W
D0GDR00Z0002 MT-GLAZE 0.000 ZA 1/10W
L6722 D0GDR00JA072 MT-GLAZE 0.000 ZA 1/10W
D0GDR00Z0002 MT-GLAZE 0.000 ZA 1/10W
TRANSISTORS
Q6329 B1CHPD000006 TR CPH3338-T-TL-E
Q6331 B1ABCE000028 TR MMBTSC3928R
B1ABDF000013 TR 2SC3928A1R
B1ABDF000024 TR 2SC3928A1S
Q6700 B1ABCE000028 TR MMBTSC3928R
B1ABDF000013 TR 2SC3928A1R
B1ABDF000024 TR 2SC3928A1S
Q6701 B1CHPD000006 TR CPH3338-T-TL-E
Q6720 B1ABCE000028 TR MMBTSC3928R
B1ABDF000013 TR 2SC3928A1R
B1ABDF000024 TR 2SC3928A1S
Q6721 B1ABCE000028 TR MMBTSC3928R
B1ABDF000013 TR 2SC3928A1R
B1ABDF000024 TR 2SC3928A1S
Q6730 B1CFRC000023 TR MCH6437-P-TL-E
Q6740 B1ABCE000028 TR MMBTSC3928R
B1ABDF000013 TR 2SC3928A1R
B1ABDF000024 TR 2SC3928A1S
Q6741 B1ABCE000028 TR MMBTSC3928R
B1ABDF000013 TR 2SC3928A1R
B1ABDF000024 TR 2SC3928A1S
Q6742 B1CFRC000023 TR MCH6437-P-TL-E
RESISTORS
R001 D0GB5R6JA040 MT-GLAZE 5.6 JA 1/10W
D0GB5R6JA072 MT-GLAZE 5.6 JA 1/10W
D0GB5R6JA090 MT-GLAZE 5.6 JA 1/10W
R002 D0GB5R6JA040 MT-GLAZE 5.6 JA 1/10W
D0GB5R6JA072 MT-GLAZE 5.6 JA 1/10W
D0GB5R6JA090 MT-GLAZE 5.6 JA 1/10W
R003 D0GB5R6JA040 MT-GLAZE 5.6 JA 1/10W
D0GB5R6JA072 MT-GLAZE 5.6 JA 1/10W
D0GB5R6JA090 MT-GLAZE 5.6 JA 1/10W
R004 D0GB5R6JA040 MT-GLAZE 5.6 JA 1/10W
D0GB5R6JA072 MT-GLAZE 5.6 JA 1/10W
D0GB5R6JA090 MT-GLAZE 5.6 JA 1/10W
R005 D0GB470J0002 MT-GLAZE 47 JA 1/10W
D0GB470JA041 MT-GLAZE 47 JA 1/10W
D0GB470JA089 MT-GLAZE 47 JA 1/10W
R006 D0GB470J0002 MT-GLAZE 47 JA 1/10W
D0GB470JA041 MT-GLAZE 47 JA 1/10W
D0GB470JA089 MT-GLAZE 47 JA 1/10W
R007 J0JCC0000371 INDUCTOR 120 OHM
R008 J0JCC0000371 INDUCTOR 120 OHM
R009 D0GB103JA041 MT-GLAZE 10K JA 1/10W
D0GB103JA072 MT-GLAZE 10K JA 1/10W
D0GB103JA089 MT-GLAZE 10K JA 1/10W
R010 D0GB101JA041 MT-GLAZE 100 JA 1/10W
D0GB101JA069 MT-GLAZE 100 JA 1/10W
D0GB101JA089 MT-GLAZE 100 JA 1/10W
R012 D0GB101JA041 MT-GLAZE 100 JA 1/10W
D0GB101JA069 MT-GLAZE 100 JA 1/10W
D0GB101JA089 MT-GLAZE 100 JA 1/10W
R013 D0GB101JA041 MT-GLAZE 100 JA 1/10W
D0GB101JA069 MT-GLAZE 100 JA 1/10W
