INITIAL BUS DATA SETUP (Cont.)
16. Select NO. 58 AFC7CBP5 (Auto Flesh / C Band Pass Filter) with ▲ or ▼ key. Adjust the data with number keys for C0.
17. Select NO. 59 DIG6ABL5MSD4BAT (OSD D/A / ABL Defeat / Mid Stop / ABL Threshold) with ▲ or ▼ key. Adjust the data
with numbers key for 64.
18. Select NO. 5A RYA (R-Y/B-Y Angle) with ▲ or ▼ key. Adjust the data with + or – key for 00.
19. Select NO. 5B CBO4CRO (Cb DC Offset / Cr DC Offset) with ▲ or ▼ key. Adjust the data with number keys for CC.
20. Select NO. 5F VL5BPF (Video Level / S BPF Sw) with ▲ or ▼ key. Adjust the data with number keys for 80.
21. Select NO. 60 EWD (E/W DC) with ▲ or ▼ key. Adjust the data with + or – key for 31.
22. Select NO. 61 EWA (E/W Amp) with ▲ or ▼ key. Adjust the data with + or – key for 18.
23. Select NO. 62 EWT (E/W Tilt) with ▲ or ▼ key. Adjust the data with + or – key for 20.
24. Select NO. 63 EWB4EWP (E/W Corner Btm / E/W Corner Top) with ▲ or ▼ key. Adjust the data with number keys for B8.
25. Select NO. 64 EWC7HLV6HSC (E/W Cor SW / H Lock V Det / H Size Comp) with ▲ or ▼ key. Adjust the data with
number keys for 06.
26. Select NO. 65 BOW4ANG (Bow Correct / Angle Correct) with ▲ or ▼ key. Adjust the data with number keys for 88.
27. Select NO. 67 HBL4HBR (H Blanking L / H Blanking R) with ▲ or ▼ key. Adjust the data with number keys for 2A.
28. Select NO. 6A YTH2YGA (Y TH / Y Gain) with ▲ or ▼ key. Adjust the data with number keys for 0D.
29. Select NO. 6B RWD6ROF4BWD2BOF (R Width / R Offset / B Width / B Offset) with ▲ or ▼ key. Adjust the data with
number keys for 10.
30. Select NO. 84 OP2 (V Guide / Tone / AV / PIP/ F/V / I-CH C En / C en Sel) with ▲ or ▼ key. Adjust the data with number
keys for 42.
31. Select NO. 8D HR (H Display Position) with ▲ or ▼ key. Adjust the data with + or – key for 18.
32. Select NO. 8E SBO (Sub Bright Offset) with ▲ or ▼ key. Adjust the data with + or – key for 07.
33. Select NO. 92 DTN (YUV Sub Tint) with ▲ or ▼ key. Adjust the data with + or – key for FC.
34. Select NO. 96 DCB (YUV Cb Offset) with ▲ or ▼ key. Adjust the data with + or – key for 00.
35. Select NO. 97 DCR (YUV Cr Offset) with ▲ or ▼ key. Adjust the data with + or – key for 00.
36. Select NO. 9B EBR (16:9 Sub Bright) with ▲ or ▼ key. Adjust the data with + or – key for FB.
37. Select NO. A1 EET (16:9 Sub E/W Tilt) with ▲ or ▼ key. Adjust the data with + or – key for FD.
38. Select NO. A2 EEP (16:9 Sub E/W Corner Top) with ▲ or ▼ key. Adjust the data with + or – key for FE.
39. Select NO. AB VFL (Filter System AV) with ▲ or ▼ key. Adjust the data with + or – key for 04.
40. Press the MENU key to turn off the Service Menu display.
— 4 —
SERVICE ADJUSTMENTS (Cont.)
