Sanyo FW32D25T - Chapter 1: Connections and Setup; Attaching TV to the Stand Base

To Next Page

To Previous Page

Note:The picture of stand installation is just for the reference, please base on the material object for

the real sample.

For FW65D25T please see B -1.

FW65D25T

FW32D25T

FW42D25T

Base

base unassembled table

stand

Note:Stand base screws

are located in the

literature package.

① ②①

Need help? sanyo-av.com 1-800-877-5032

B - 1

③

Model Mounting screws measurements

①

M4 (4mm) Diameter, Length-12mm (maximum) x 4

②

ST4 (4mm) Diameter, Length-20mm (maximum) x 4

①

M5 (5mm) Diameter, Length-12mm (maximum) x 4

②

ST4 (4mm) Diameter, Length-20mm (maximum) x 4

③

M5 (5mm) Diameter, Length-20mm (maximum) x 4

Other manuals for Sanyo FW32D25T
