6
–
EN
ABOUT SOUNDBAR
Soundbar
Top / front panels of soundbar
LED indicators LED color Description
POWER
(Standby indicator)
red
On when soundbar is in standby mode.
Off when soundbar is turned on.
AUX(iliary) INPUT
orange On up when you switch to analog input source.
LINE INPUT
orange On when you switch to line-in source (3.5 mm jack).
OPTICAL INPUT orange On when you switch to optical input source.
PAIR(ing) INPUT
(Bluetooth)
blue
On when you switch to Bluetooth mode and Bluetooth
compatible devices are paired.
Blinks when Bluetooth pairing is activated and pairing failed.
Back connectors on soundbar
4
1
2
3
OPTICALOPTICAL IN
LINE
LINE IN
AUX
AUX IN
Connectors Description
1
AUX(iliary) IN(put)
Connect to an analog audio output on the TV or an analog device.
2
LINE IN(put)
Connect to a TV or an MP3 player.
3
OPTICAL IN(put)
Connect to an optical digital audio output on the TV or a digital device.
4
Wall mount hooks
Install on a wall if desired.
