GB–21
ACCESSORIES AND HARDWARE
INSTALLATION
Mounting Bracket Mounting Strap Locking Screw
(Half Sleeve)× 1 and Screws × 1 × 1
Removable Trim Ring Unlock Levers
× 1 × 2
INSTALLATION
1. BEFORE INSTALLATION
When mounting the unit in a car, keep the unit as level as possible.
If the unit must be mounted at an angle, due to the design of the vehicle, make sure the unit does not tilt by
more than 30°.
max. 30°
