2. Troubleshooting guide
2.1. No raster
Turn-on power supply, check
if the red indicator is light in
the STANDBY?
Check if 5VSTB of X808 11#
on main board is normal?
Check STANDBY circuit of
power supply board
Press POWER button on the
unit or sensor control an
d
check the indicator.
Check if the PIN1 of X808 on
main board is high-level?
Check if the PIN13 of X808 on
main board is high-level?
Check power
supply board
Check power board and
back light board
yes
no
no
red
blue
yes
Check the backlight
control circuit on the
main board
no
yes
