Sanyo MCD-UB575M Service Manual

- 1 -
• Pickup that emits a laser beam is used on this CD section.
CAUTION :
USE OF CONTROLS OR ADJUSTMENTS OR
PERFORMANCE OF PROCEDURES OTHER
THAN THOSE SPECIFIED HEREIN MAY RESULT
IN HAZARDOUS RADIATION EXPOSURE.
LASER OUTPUT................ 0.6 mW Max. (CW)
WAVE LENGTH ................. 790 nm
LASER BEAM SAFETY PRECAUTION
CLASS 1 LASER PRODUCT
LUOKAN 1 LASERLAITE
KLASS 1 LASERAPPARAT
CAUTION-INVISIBLE LASER RADIATION WHEN OPEN AND
INTERLOCKS DEFEATED. AVOID EXPOSURE TO BEAM.
ADVARSEL-USYNLIG LASER STRÅLING VED ÅBNING, NÅR
SIKKERHEDSAFBRYDERE ER UDE AF FUNKTION, UNDGÅ
UDS ÆTTELSE FOR STRÅLING.
VARNING-OSYNLIG LASER STRÅLNING NÄR DENNA DEL
ÄR ÖPPNAD OCH SPÄRR ÄR URKOPPLAD. STRÅLEN ÄR
FARLIG.
VORSICHT! -UNSICHTBARE LASERSTRAHLUNG TRITT
AUS, WENN DECKEL GEÖFFNET UND ENN
SICHERHEITSVERRIEGELUNG ÜBERBRÜCKT IST. NICHT,
DEM STRAHL AUSSETZEN.
VARO !- AVATTAESSA JA SUOJALUKITUS OHITETTAESSA
OLET ALTTIINA NÄKYMÄTTÖMÄLLE LASERSÄTEILYLLE.
ÄlÄ KATSO SÄTEESEEN.

Sanyo MCD-UB575M Specifications

CD Player

channels	2-Channel stereo
sampling frequency	44.1 kHz
laser output	0.6 mW
wave length	790 nm

Radio

FM reception frequency	87.5 - 108 MHz
AM reception frequency	526.5 - 1606.5 kHz

Cassette Deck

track system	4-track, 2-channel stereo
tape speed	4.75 cm/sec.
frequency response	80 - 12, 000 Hz

General Specifications

output power (DC)	2 W/ch
output power (AC)	1.5 W/ch
speakers	10 cm x 2, 8 ohms
dimensions	410 (W) x 167 (H) x 286 (D) mm
weight	Approx. 2.8 kg
power source (AC)	110 V, 60 Hz
power source (DC)	12V, 8 “D/HP2/R20” batteries
