Battery accumulating
time :
F03: Battery accumulating time is displayed.
(Ex. 2years and 6months consumed 㸢㩷 displayed as ‘02.5’)
The display shows ’02.8’ to inform the battery exhaustion.
Replace with new battery.
<Reset of accumulating time>
Step into F06. Input ‘409’ and press SET key to turn the display
to ’00.0’ with BATTERY lamp goes off.
Condensing fan
motor accumulating
time :
F32: Condensing fan motor accumulating time is displayed.
(Ex. 5years and 6months consumed 㸢 displayed as ’05.5’)
<Reset of accumulating time>
Step into F06. Input ‘419’ and press SET key to turn the display
to ’00.0’ with DP55 lamp goes off.
Note) Notice of condensing fan motor accumulating time is prior to
notice of battery accumulating time.
ROM version :
F30: ROM version is displayed (Ex. Ver. 1.00 㸢㩷 displayed as “1.00”)
Monitor of status : DP52 (orange lamp) is lit in the following status;
Status 1; When the ambient temperature is over 35.0C or lower than
0C. Press STATUS key once to display ‘- - 1’.
Status 2; When the power source voltage is less than 2.01 VDC
between TP7 and TP3. Press STATUS key once to display
‘- - 2’,
Status 3; When running rate of refrigerating circuit is higher than
usual.
When diagnose value of running rate is 95% or higher, the display
shows ‘- - 3’.
Display on temperature indicator:
Status code displayed is changed every few seconds if two or three
status shown at the same time.
order: (‘- - 1’ 㸢 ‘- - 2’ 㸢㩷 ‘- - 3’ 㸢 ‘- - 1’ …… )
7. Function mode
F00 Automatically revert to PV display
F01 SV
H
(high temp. alarm SV) setting
F02 SV
L
(low temp. alarm SV) setting
F03 Battery accumulating time display
F04 Door alarm delay time setting
F05 Compressor (H)/(L) delay time setting
F06 Service code input (code: 384)
F07 * Temperature Zero Adjustment
F08 * Cascade sensor Zero Adjustment
F09 Factory test mode …… Unavailable
F10 Factory test mode …… Unavailable
F11 Factory test mode …… Unavailable
F12 * Display of temperature of temp. sensor
F13 * Display of temperature of cascade sensor
F14 * Display of temperature of filter sensor
F15 * Display of temperature of AT sensor
F16 Automatically revert to PV display
F17 * Model code setting (Initialization of non-volatile ROM and memory)
F18 * Capillary heater is forcibly turned on/off
F19 Factory test mode …… Unavailable
F20 * Setting for Diagnose value of running rate …… Unavailable
F21 Communication ID set
F22 Communication mode set
F23 * Display of power supply voltage
F24 Remote alarm terminal output
F25 Ring-back time set
To Next Page
