2. SPECIFICATIONS
2-1. Unit Specifications
Outdoor Unit SAP–CMRV3143GJ
Type 4-room multi outdoor unit
Number of connectable indoor units 4
Maximum capacity of connected indoor u
kW 15.4
Maximum capacity of operating indoor units kW 15.4
Power Source 220–240V ~ 50Hz 220V ~ 60Hz
Voltage rating 230 V 220 V
Performance Cooling Cooling
Capacity kW 9.0 (1.2 - 10.5) 9.0 (1.2 - 10.5)
BTU/h 30,700 30,700
Air circulation (High)
m
3
/h
2,800 2,800
Electrical Rating Cooling Cooling
Available voltage range V 198 ~ 264 198 ~ 242
Running amperes A 8.8 (Max.15.5) 8.8 (Max.15.5)
Power input W 1,940 1,940
Power factor % 96 96
C.O.P. W/W 4.64 4.64
Starting amperes A 12.7 12.7
Features
Controls Microprocessor
Fan speeds Auto (Hi, Lo)
Compressor Twin Rotary (DC inverter)
Refrigerant / Amount charged at shipment g R410A / 4,000
Refrigerant control Electric Expansion Valve
Operation sound Hi dB-A 53 53
Refrigerant tubing connections Flare type
Max. allowable tubing length per unit m 30
Refrigerant Narrow tube mm (in.)
6.35(1/4) × 4
tube diameter Wide tube mm (in.)
9.52(3/8) × 3
mm (in.)
12.7(1/2) × 1
Dimensions & Weight
Unit dimensions Height mm 880
Width mm 940
Depth mm 340
Package dimensions Height mm 981
Width mm 1,016
Depth mm 440
Weight Net kg 90
Shipping kg 92
Shipping volume
m
3
0.439
DATA SUBJECT TO CHANGE WITHOUT NOTICE.
2. Rating conditions are:
Cooling : Indoor air temperature 27°C D.B. / 19°C W.B.
Outdoor air temperature 35°C D.B. / 24°C W.B.
Remarks:
1. The value shown in performance section and electrical rating section above are based on the following unit
combination. For other combination of indoor units, please refer to the "Unit Combination Table" in this manual.
Indoor unts: SAP-KMRV93GJ 4 units
(Outdoor unit: SAP-CMRV3143GJ 1 unit )
