9
Indoor Unit SAP–DMRV243GJ
DATA SUBJECT TO CHANGE WITHOUT NOTICE.
Control PCB
Part No. POW-DMRV243GJ
Controls Microprocessor
Control circuit fuse 2.50V 3.15A
Flap Motor and Louver Motor
Type —
Model —
Rating —
Coil resistance (Ambient temp. 25°C) Ω —
Heat Exchanger Coil
Coil Aluminum plate fin / Copper tube
Rows 3
Fin pitch mm 1.3
Face area m
2
0.147
Fan & Fan Motor
Type Centrifugal fan
Q’ty … Dia. and length mm 2 … ø144/L162
Fan motor model … Q’ty KFG4X-91A5P-S
No. of poles … rpm (230V, High) 4 … 1330
Nominal output W 90
Coil resistance (Ambient temp. 20°C) Ω BRN – WHT: 87.1 ORG – YEL: 32.3
WHT – VLT: 15.1 YEL – BLK: 143.8
VLT – ORG: 111.8 BLK – PNK: 103.6
Safety devices Type Thermal protector
Operating temp. Open °C 130 ± 8
Close Automatic reclosing
Run capacitor µF 3.5
VAC 440
Remote Control Unit RCS-3MVPS4E
