1. Specifications
1
2
3
4
5
I-97
SM830080
1-10 Air throw Distance Chart
4-Way Air Discharge Semi-concealed Type
Model: 25 Type
Model: 36, 48 Type
0123456
0
1
2
3
4
HORIZONTAL DISTANCE (m)
AXIS AIR VELOCITY (m/s)
VERTICAL DISTANCE (m)
AXIS AIR VELOCITY
0276_X_I
0123456
0
1
2
3
4
HORIZONTAL DISTANCE (m)
AXIS AIR VELOCITY (m/s)
VERTICAL DISTANCE (m)
AXIS AIR VELOCITY
0277_X_I
: LOUVER ANGLE 20˚ in Cooling mode
: LOUVER ANGLE 60˚ in Heating mode
Condition Fan Speed : Hi
Room air temp. : 27 ˚C DB in cooling mode
20 ˚C DB in heating mode
