HOW TO USE THIS MANUAL
This manual is designed to help service personnel to understand basic functions, operation and possible problems
and their remedies on SANYO Packaged Terminal Air Conditioner. You can use this manual both as a reference to
find specific information about the capacity and construction of the unit, and as a source of information to help you
set up and maintain the air conditioner. Please use this manual to make your work easier, keep the air conditioner
functioning well, and keep your customer satisfied.
Please read IMPORTANT! precaution information on the previous page before you start actual work.
SANYO PACKAGED TERMINAL A/C MODEL IDENTIFICATION
SANYO Packaged Terminal Air Conditioner is identified by a model number. Cooling or heating capacity, electrical
information and special features included on the air conditioner are indicated in the model number.
SANYO Package Terminal A/C Development
Nominal Cooling Capacity Unit Type
06: 6,000BTU 12: 12,000BTU C: Cooling Only W/E. Heater
09: 9,000BTU 15: 15,000BTU H: Heat Pump W/E. Heater
Voltage Heater size
2: 230/208 V Refer to the table below
3: 265 V
Heater 230 / 208 V Models
Designator Heater Amp Watts Min. Amp BTU/h
2 11.1 / 10.4 2,550 / 2,090 15 8,600 / 7,100
3 15.5 / 14.0 3,450 / 2,820 20 11,700 / 9,600
5 22.4 / 20.2 5,000 / 4,090 30 17,000 / 13,900
265 V Models
Heater Amp Watts Min. Amp BTU/h
3 11.4 3,000 15 10,200
4 15.2 4,000 20 13,600
5 19.0 5,000 30 17,000
NOTE
To identify the correct model number of your air conditioner, locate the nameplate.
The nameplate is usually located above the electric component box (behind the grille).
Remove the grille to access the electric component box.
