Sanyo VCC-4594P - Table of Contents

Depending on the conditions of use, installation and environment,
please be sure to make the appropriate settings and adjustments. If
you need help with installation and/or settings, please consult your
dealer.
CONTENTS
PRECAUTIONS........................................................................................2
PARTS NAMES........................................................................................ 3
CONCERNING AUTO-IRIS LENSES......................................................... 5
FLANGE-BACK ADJUSTMENT................................................................ 6
MOUNTING THE LENS........................................................................... 7
CONNECTIONS.......................................................................................9
SETTINGS................................................................................................11
TROUBLESHOOTING..............................................................................17
SPECIFICATIONS.....................................................................................18
FEATURES
• The optical filter is switched automatically to colour image or
black and white image according to the subject brightness.
• Built-in interline transfer method 1/3" CCD, approx. 410,000
picture elements
• Low smear, anti-blooming, low lag, no burning and no geometric
distortion using the CCD solid state image device.
• 100% solid state components giving excellent immunity to shock
and vibration
• Not subject to interference from magnetic or electrostatic fields
• High sensitivity, minimum required illumination is 0.03 lux (F1.2)
B/W mode
• Horizontal resolution, more than 520 TV lines
• Power supply: 24 V AC operation (VCC-4594P)
12 V DC operation (VCC-4592P)
ACCESSORIES
1 Lens iris plug (4-pin) ..................................................................1 pc.
2 Clamping core A .......................................................................2 pc.
3 Clamping core B........................................................................3 pc.
123
L53Z4/XE GB 2001, 5, 23
English 1
