21
Note:
1. Materials of Capacitors and Resistors are abbreviated as follows ;
Resistors Capacitors
MT-FILM Metallized Film Resistor MT-POLYEST Metallized Polyester Capacitor
MT-GLAZE Metallized Glaze Resistor MT-COMPO Metallized Composite Capacitor
OXIDE-MT Oxide Metallized Film Resistor TA-SOLD Tantalum Solid Capacitor
AL-SOLID Aluminum Solid Capacitor
NP-ELECT Non-Polarized Electrolytic Capacitor
OS-SOLID Aluminum Solid Capacitors with Organic
Semiconductive Electrolytic Capacitor
DL-ELECT Double Layered Electrolytic Capacitor
2. Tolerance of Capacitor (10pF over) and Resistor are noted with follow symboles.
F ............1% G ............2% J ............5% K ............10%
M ..........20% N ..........30% Z ..........+80% ~ -20%
3. Capacitors
U :
µ
FP : pF
4. Inductors
UH :
µ
H MH : mH
5. N.S.P. : Not available as service parts.
LOCATION PARTS NO. DESCRIPTION LOCATION PARTS NO. DESCRIPTION
ELECTRICAL PARTS
COMPL,CA-1 SV-SX612
636 068 9848
(CAPACITORS)
C9001 403 157 1904 CERAMIC 10P D 50V
C9002 403 314 5905 CERAMIC 0.47U K 16V
C9003 403 314 5905 CERAMIC 0.47U K 16V
C9004 403 314 5905 CERAMIC 0.47U K 16V
C9005 403 314 5905 CERAMIC 0.47U K 16V
C9014 403 338 4403 CERAMIC 0.1U K 16V
C9016 403 283 6309 CERAMIC 1U Z 10V
C9017 403 333 3708 CERAMIC 10U M 10V
C9019 403 338 4403 CERAMIC 0.1U K 16V
C9020 403 332 8209 CERAMIC 10U M 16V
C9021 403 332 8209 CERAMIC 10U M 16V
C9022 403 320 5500 CERAMIC 1U Z 25V
(SEMICONDUCTOR)
Q9002 405 153 6709 TR 2SC3931-D
(RESISTORS)
R9015 401 105 7503 MT-GLAZE 82K JA 1/16W
R9020 401 105 0405 MT-GLAZE 100 JA 1/16W
R9021 401 105 4106 MT-GALZE 3.3K JA 1/16W
R9022 401 105 7909 MT-GLAZE 0.000 ZA 1/16W
(MISCELLANEOUS)
409 529 5907 IC ICX274AQF-C (N.S.P.)
636 066 5422 MOUNTING,LENS (N.S.P.)
COMPL PWB,CA-2
636 066 4579
(CAPACITORS)
C1001 403 345 3802 TA-SOLID 22U M 4V
C1002 403 346 2309 CERAMIC 0.1U K 10V
C1004 403 346 2309 CERAMIC 0.1U K 10V
C1005 403 346 2309 CERAMIC 0.1U K 10V
C1006 403 345 3802 TA-SOLID 22U M 4V
C1007 403 343 3101 CERAMIC 1U K 6.3V
C1008 403 346 2309 CERAMIC 0.1U K 10V
C1009 403 369 0306 CERAMIC 1U Z 4V
C1010 403 345 3802 TA-SOLID 22U M 4V
C1011 403 346 2309 CERAMIC 0.1U K 10V
C1012 403 346 2309 CERAMIC 0.1U K 10V
C1015 403 345 4205 TA-SOLID 47U M 6.3V
C1016 403 311 3409 CERAMIC 0.01U K 16V
C1017 403 311 3409 CERAMIC 0.01U K 16V
C1019 403 311 3409 CERAMIC 0.01U K 16V
C1021 403 311 3409 CERAMIC 0.01U K 16V
C1023 403 311 3409 CERAMIC 0.01U K 16V
C1025 403 346 2309 CERAMIC 0.1U K 10V
C1027 403 346 2309 CERAMIC 0.1U K 10V
C1028 403 329 6508 TA-SOLID 10U M 6.3V
C1029 403 345 3802 TA-SOLID 22U M 4V
C1031 403 346 2309 CERAMIC 0.1U K 10V
C1032 403 311 3409 CERAMIC 0.01U K 16V
C1033 403 311 3409 CERAMIC 0.01U K 16V
C1034 403 346 2309 CERAMIC 0.1U K 10V
C1035 403 346 2309 CERAMIC 0.1U K 10V
C1036 403 311 3409 CERAMIC 0.01U K 16V
C1037 403 311 3409 CERAMIC 0.01U K 16V
C1038 403 311 3409 CERAMIC 0.01U K 16V
C1039 403 311 3409 CERAMIC 0.01U K 16V
C1040 403 346 2309 CERAMIC 0.1U K 10V
C1041 403 346 2309 CERAMIC 0.1U K 10V
C1042 403 311 3409 CERAMIC 0.01U K 16V
C1043 403 311 3409 CERAMIC 0.01U K 16V
C1044 403 346 2309 CERAMIC 0.1U K 10V
C1045 403 346 2309 CERAMIC 0.1U K 10V
C1046 403 311 3409 CERAMIC 0.01U K 16V
C1047 403 369 0306 CERAMIC 1U Z 4V
C1048 403 369 0306 CERAMIC 1U Z 4V
C1050 403 346 2309 CERAMIC 0.1U K 10V
C1052 403 346 2309 CERAMIC 0.1U K 10V
C1053 403 311 4505 CERAMIC 1000P K 50V
C1054 403 311 4505 CERAMIC 1000P K 50V
C1055 403 311 4505 CERAMIC 1000P K 50V
C1056 403 311 4505 CERAMIC 1000P K 50V
C1057 403 329 6508 TA-SOLID 10U M 6.3V
C1101 403 343 3101 CERAMIC 1U K 6.3V
C1102 403 311 3409 CERAMIC 0.01U K 16V
C1113 403 346 2309 CERAMIC 0.1U K 10V
C1201 403 346 2309 CERAMIC 0.1U K 10V
C1302 403 343 3101 CERAMIC 1U K 6.3V
C1401 403 312 6805 CERAMIC 0.1U Z 16V
C1402 403 312 6805 CERAMIC 0.1U Z 16V
C1404 403 312 6805 CERAMIC 0.1U Z 16V
C1405 403 329 6508 TA-SOLID 10U M 6.3V
C1406 403 312 6805 CERAMIC 0.1U Z 16V
C1501 403 311 5007 CERAMIC 33P J 50V
C1502 403 369 0306 CERAMIC 1U Z 4V
C1503 403 343 3101 CERAMIC 1U K 6.3V
C1504 403 345 3802 TA-SOLID 22U M 4V
C1505 403 345 4205 TA-SOLID 47U M 6.3V
C1506 403 343 3101 CERAMIC 1U K 6.3V
C1507 403 311 7506 CERAMIC 22P J 50V
C1701 403 346 2309 CERAMIC 0.1U K 10V
C1702 403 369 0306 CERAMIC 1U Z 4V
C1703 403 369 0306 CERAMIC 1U Z 4V
C1704 403 343 3101 CERAMIC 1U K 6.3V
C1705 403 343 3101 CERAMIC 1U K 6.3V
C1706 403 346 2309 CERAMIC 0.1U K 10V
C1707 403 346 2309 CERAMIC 0.1U K 10V
C1708 403 343 3101 CERAMIC 1U K 6.3V
C1709 403 346 2309 CERAMIC 0.1U K 10V
C1710 403 346 2309 CERAMIC 0.1U K 10V
C1711 403 346 2309 CERAMIC 0.1U K 10V
C1712 403 369 0306 CERAMIC 1U Z 4V
C1713 403 311 3409 CERAMIC 0.01U K 16V
C1714 403 348 9108 CERAMIC 0.47U K 6.3V
To Next Page
