Sanyo VPC-MZ3EX User Manual

24
LOCATION PARTS NO. DESCRIPTION LOCATION PARTS NO. DESCRIPTION
C9521 403 367 9004 TA-SOLID 47U M 10V
C9522 403 312 6805 CERAMIC 0.1U Z 16V
(DIODES)
D5001 407 190 3703 DIODE RB050L-40-TE25
D5002 407 190 3703 DIODE RB050L-40-TE25
D5004 407 203 5809 DIODE F02J9
D5005 407 203 5809 DIODE F02J9
D5006 407 210 1900 DIODE 1SS400
D5007 407 223 2604 DIODE CRS06
D5008 407 223 2604 DIODE CRS06
D5009 407 210 5403 DIODE RB551V-30
D5011 407 201 2701 DIODE RB051L-40
D5012 407 187 8407 ZENER DIODE UDZ16B
D5013 407 162 8507 DIODE DAN222
D9507 407 201 2701 DIODE RB051L-40
(INTEGRATED CIRCUITS)
IC501 409 530 4609 IC FA7709R
IC502 409 301 5507 IC TC7S08FU
IC951 409 512 9806 IC LB8649FN
IC952 409 526 4002 IC XC9104D095M
IC953 409 532 0104 IC UPD168110MA-6A5
(JACK)
JK501 645 027 7030 SOCKET,DC
(INDUCTORS)
L1602 645 037 4340 INDUCTOR,1000 OHM
L1603 645 037 4340 INDUCTOR,1000 OHM
L1604 645 037 4340 INDUCTOR,1000 OHM
L5001 645 041 1977 INDUCTOR,330 OHM
L5002 645 041 1953 INDUCTOR,100 OHM
L5003 645 041 1953 INDUCTOR,100 OHM
L5004 645 037 1530 INDUCTOR,47U K
L5005 645 037 1530 INDUCTOR,47U K
L5006 645 037 1530 INDUCTOR,47U K
L5007 645 037 1523 INDUCTOR,10U K
L5008 645 055 8047 INDUCTOR,10U M
L5009 645 052 7432 INDUCTOR,10U M
L5010 645 036 7496 INDUCTOR,4.7U M
L5011 645 046 1941 INDUCTOR,10U M
L5012 645 046 1941 INDUCTOR,10U M
L5013 645 037 1530 INDUCTOR,47U K
L9501 645 052 7432 INDUCTOR,10U M
(FUSES)
PR501 423 029 3706 FUSE 32V 2.5A
PR502 423 028 0904 FUSE 32V 2A
PR503 423 028 0904 FUSE 32V 2A
PR504 423 028 1505 FUSE 32V 1A
PR505 423 029 3706 FUSE 32V 2.5A
(SEMICONDUCTORS)
Q5001 405 163 3606 TR CPH3409
Q5002 405 137 2000 TR 2SA1576A-R
Q5003 405 092 2107 TR 2SC4097-R
Q5004 405 165 1204 TR EMD2
Q5005 405 165 1105 TR EMH11
Q5006 405 157 1403 TR 2SA2018
Q5007 405 170 6409 TR DTA114YM
Q5008 405 115 5207 TR 2SC4617 R
Q5009 405 162 3706 TR CPH3313
Q5010 405 163 2302 TR CPH3307
Q5011 405 148 7100 TR CPH6401
Q5012 405 164 6408 TR MCH5803
Q5013 405 115 5108 TR 2SA1774 R
Q5014 405 169 4508 TR DTC114EM
Q5015 405 162 4000 TR CPH5803
Q5016 405 157 1403 TR 2SA2018
Q5017 405 168 3700 TR DTC144EM
Q5018 405 157 1403 TR 2SA2018
Q5019 405 169 4508 TR DTC114EM
Q5021 405 170 6409 TR DTA114YM
Q5022 405 168 3700 TR DTC144EM
Q9504 405 148 7100 TR CPH6401
Q9505 405 168 3700 TR DTC144EM
Q9506 405 162 4109 TR CPH6311
(RESISTORS)
R5001 401 224 9402 MT-GLAZE 1.0M JA 1/16W
R5002 401 226 1503 MT-GLAZE 0.000 ZA 1/16W
R5013 401 261 2602 MT-FILM 10K DU 1/16W
R5015 401 224 9402 MT-GLAZE 1.0M JA 1/16W
R5016 401 226 1503 MT-GLAZE 0.000 ZA 1/16W
R5017 401 224 9402 MT-GLAZE 1.0M JA 1/16W
R5018 401 226 1503 MT-GLAZE 0.000 ZA 1/16W
R5019 401 224 9402 MT-GLAZE 1.0M JA 1/16W
R5020 401 226 1503 MT-GLAZE 0.000 ZA 1/16W
R5021 401 224 9402 MT-GLAZE 1.0M JA 1/16W
R5022 401 226 1503 MT-GLAZE 0.000 ZA 1/16W
R5023 401 226 1503 MT-GLAZE 0.000 ZA 1/16W
R5033 401 226 1503 MT-GLAZE 0.000 ZA 1/16W
R5034 401 224 8900 MT-GLAZE 100K JA 1/16W
R5035 401 261 7805 MT-FILM 62K DD 1/16W
R5036 401 224 8900 MT-GLAZE 100K JA 1/16W
R5037 401 261 9304 MT-FILM 15K DD 1/16W
R5038 401 225 1702 MT-GLAZE 39K JA 1/16W
R5039 401 224 9006 MT-GLAZE 10K JA 1/16W
R5040 401 224 9303 MT-GLAZE 1K JA 1/16W
R5041 401 258 7009 MT-GLAZE 150K DC 1/16W
R5042 401 261 2602 MT-FILM 10K DU 1/16W
R5043 401 261 5900 MT-FILM 330 DU 1/16W
R5044 401 262 3400 MT-FILM 39 DD 1/16W
R5045 401 224 8900 MT-GLAZE 100K JA 1/16W
R5046 401 227 5609 MT-GLAZE 8.2K JA 1/16W
R5047 401 261 8703 MT-FILM 22K DD 1/16W
R5048 401 224 8900 MT-GLAZE 100K JA 1/16W
R5049 401 224 9006 MT-GLAZE 10K JA 1/16W
R5050 401 258 7009 MT-GLAZE 150K DC 1/16W
R5051 401 225 8008 MT-GLAZE 330 JA 1/16W
R5052 401 225 8008 MT-GLAZE 330 JA 1/16W
R5053 401 225 8008 MT-GLAZE 330 JA 1/16W
R5054 401 261 9304 MT-FILM 15K DD 1/16W
R5056 401 224 9402 MT-GLAZE 1.0M JA 1/16W
R5057 401 226 1503 MT-GLAZE 0.000 ZA 1/16W
R5061 401 225 0705 MT-GLAZE 56K JA 1/16W
R5062 401 226 1503 MT-GLAZE 0.000 ZA 1/16W
R5063 401 224 9303 MT-GLAZE 1K JA 1/16W
R5064 401 261 9106 MT-FILM 12K DD 1/16W
R5066 401 261 2602 MT-FILM 10K DU 1/16W
R5067 401 261 3500 MT-FILM 3.9K DU 1/16W
R5068 401 261 6501 MT-FILM 220 DU 1/16W
R5071 401 225 0705 MT-GLAZE 56K JA 1/16W
R5072 401 226 1503 MT-GLAZE 0.000 ZA 1/16W
R5073 401 224 9303 MT-GLAZE 1K JA 1/16W
R5074 401 261 9106 MT-FILM 12K DD 1/16W
R5076 401 261 2701 MT-FILM 4.7K DU 1/16W
R5077 401 261 6105 MT-FILM 390 DU 1/16W
R5078 401 262 3608 MT-FILM 18 DD 1/16W
R5081 401 226 1503 MT-GLAZE 0.000 ZA 1/16W
R5082 401 224 9303 MT-GLAZE 1K JA 1/16W
R5083 401 261 8703 MT-FILM 22K DD 1/16W
R5084 401 261 2909 MT-FILM 5.6K DU 1/16W
R5085 401 261 5900 MT-FILM 330 DU 1/16W
R5086 401 262 3608 MT-FILM 18 DD 1/16W
R5091 401 226 1503 MT-GLAZE 0.000 ZA 1/16W
R5092 401 224 8900 MT-GLAZE 100K JA 1/16W
R5093 401 284 3600 MT-GLAZE 16K JA 1/16W
R5094 401 237 2407 MT-GLAZE 270K JA 1/16W
R5095 401 224 9303 MT-GLAZE 1K JA 1/16W
R5096 401 224 9006 MT-GLAZE 10K JA 1/16W
R5097 401 226 1503 MT-GLAZE 0.000 ZA 1/16W
R5098 401 261 9601 MT-FILM 68 DD 1/16W
R5101 401 226 1503 MT-GLAZE 0.000 ZA 1/16W
R5102 401 224 8900 MT-GLAZE 100K JA 1/16W
R5103 401 224 9006 MT-GLAZE 10K JA 1/16W
R5104 401 224 9303 MT-GLAZE 1K JA 1/16W
R5105 401 261 8703 MT-FILM 22K DD 1/16W
R5106 401 261 2701 MT-FILM 4.7K DU 1/16W
R5107 401 261 5306 MT-FILM 470 DU 1/16W
R5108 401 262 3202 MT-FILM 33 DD 1/16W
R5112 401 224 8900 MT-GLAZE 100K JA 1/16W
R5113 401 224 9006 MT-GLAZE 10K JA 1/16W
R5115 401 237 2407 MT-GLAZE 270K JA 1/16W
R5120 401 225 1207 MT-GLAZE 4.7K JA 1/16W
R5124 401 224 8900 MT-GLAZE 100K JA 1/16W
R5128 401 226 1503 MT-GLAZE 0.000 ZA 1/16W
R5130 401 226 1503 MT-GLAZE 0.000 ZA 1/16W
R9501 401 293 8504 MT-FILM 0.68 FA 1/4W
R9503 401 261 8901 MT-FILM 27K DD 1/16W
R9504 401 261 8901 MT-FILM 27K DD 1/16W
R9505 401 261 2503 MT-FILME 9.1K DU 1/16W
