Individual ID Codes
(Identifiers)
You can assign ID codes (such as prod-
uct name, batch number, etc.) while
weighing, for identification of measured
values.
Features
– Assign up to two ID codes.
– Assign both a name and a value
for each ID code.
– The name is left-justified and the
value is right-justified on the printout.
If the entire code is too long for one
line, additional lines are printed.
– Enter ID code names in Setup under:
Setup: prtprot (printouts):
7.4.3 (ID1)
and
7.4.4 (ID2)
–
Enter up to 20 characters for the ID code
name. No more than 11 characters are
displayed during input; all 20 characters
are printed.
– Maximum length for values:
21 characters.
– Enter numeric values for ID codes
using the numeric keypad and press
g or h to save.
– To delete the last character entered
in the ID code value: Press E
To delete the entire ID code:
Press E and then g or h
– If both the name and value fields are
empty, no ID code is printed.
– Print ID codes: Refer to the Setup menu
for menu item numbers.
Data is output to COM1 menu item
7.7.x) or UniCOM (menu item 7.8.x).
– Show ID codes:
Press I and then g or h
– To store values entered using a bar code
scanner: Scan the value for ID1
Function Keys
g Store the input as
or value for first or
h second ID code.
E Delete the selected ID code value
I Display ID codes
Application Parameters: ID Codes
Setup
PrtProt Printouts
7.4. Input
ID code name
7.4.3 ID1
7.4.4 ID2
7.7 COM1: Configure
printout
7.7.6 ID1 and ID2
7.8 UniCOM:
Configure
printout
7.8.6 ID1 and ID2
18
Operating the Combics 1 plus
