Setup
Com1
2
Interface 1
(Display designation of this menu level: 2)
off * Off
WP2 Weighing Instrument 2
rs-232 *
RS-232
sbi-std SBI Standard Version
sbi-app SBI trade version (for legal metrology)
bpi-232 * XBPI-232
1
)
1. 1. through 1.8.
Numeric menu as for WP1
1. 9. Calibration, Adjustment
1. 9. 1 * Ext. calibration/adjustment; default weight
1. 9. 3 Ext. calibration/adjustment; weight can be selected under menu item 1.18.1
1. 9. 4 Internal calibration/adjustment
1. 9.10 Press ) > 2 sec: blocked
1.10. through 9.1.
Numeric menu as for WP1
adc-232 ADC-232
1
)
1. 1. through 9.1.
Numeric menu as for WP1
datProt Data Protocol
sbi *
SBI Standard Version
5. 1. Baud rate
5. 1. 1 150 baud
5. 1. 2 300 baud
5. 1. 3 600 baud
5. 1. 4 * 1200 baud
5. 1. 5 2400 baud
5. 1. 6 4800 baud
5. 1. 7 9600 baud
5. 1. 8 19,200 baud
5. 2. Parity
5. 2. 2 Space
2
)
5. 2. 3 * Odd
5. 2. 4 Even
5. 2. 5 None
3
)
5. 3. Number of Stop Bits
5. 3. 1 * 1 stop bit
5. 3. 2 2 stop bits
5. 4. Handshake Mode
5. 4. 1 Software handshake
5. 4. 3 * Hardware handshake, 1 character after CTS
5. 6. Number of Data Bits
5. 6. 1 * 7 data bits
5. 6. 2 8 data bits
6. 1. Data Output: Manual/Automatic
6. 1. 1 Manual without stability
6. 1. 2 * Manual after stability
6. 1. 4 Automatic without stability
6. 1. 5 Automatic with stability
6. 1. 7 Protocol for computer
1
) = Menu depends on weighing instrument model
2
) = not with setting 5.6.2 (8 bits)
3
) = Not with setting 5.6.1 (7 bits)
