2
Contents Intended Use
2 Contents
2 Intended Use
2 Configuring the Interface
Parameter Settings (Menu)
3 Data Output Functions
3 Printing a Data Record
5 Interface Description
5 Data Output Format
9 Data Input Format
12 Cabling Diagram
The interface can be used to connect
the balance/scale to a computer
(or other peripheral device).
You can use a computer to change,
start and monitor balance/scale functions
and applications.
Available Features
– Type of interface: Serial interface
– Operating mode: Full duplex
– Standard: RS-232
– Transmission rates: 150, 300, 600,
1,200, 2,400, 4,800, 9,600 baud
– Parity: Mark, space, odd, even
– Character format: Start bit,
7-bit ASCII, parity, 1 or 2 stop bits
– Handshake:
2-wire interface: via software
(XON/XOFF)
4-wire interface: via hardware
(CTS/DTR)
– Protocol: SBI (Sartorius Balance
Interface)
– Data output format of the
balance/scale: 16 or 22 characters
Configuring the
Interface
Parameter Settings (Menu)
Please refer to the installation and
operating instructions supplied with
your balance/scale.
