Leveling the Balance/Scale
§ Always level the balance/scale again any time after it
has been moved to a different location.
Example: moving bubble from R to L
§ Turn the feet as shown in the diagram until the
air bubble is centered within the circle of the level
indicator.
> In most cases this will require several adjustment
steps.
Removing Weights for Calibration/Span
Adjustment
(only for models ELT103, ELT602, ELT402, ELT202,
ELT1001, ELT601, GD502)
§ Grasp the tab to turn and pull out the weight
compartment.
$ Follow instructions on page 14 for calibration/span
adjustment.
6
