Output Format (Line Format)
You can output the values displayed in the
line for measured values and the weight
unit with or without a data ID code
Example: Without data ID code
+ 253 pcs
Example: With data ID code
Qnt + 253 pcs
Configure this parameter in the Setup
menu (Setup: Printout: Line format).
The output with a data ID code has
16 characters; without a data ID code,
22 characters.
Output Format With 16 Characters
Display segments that are not activated
are output as spaces. Characters without
a decimal point are output without a
decimal point.
134
The following characters can be output, depending on the characters displayed on the balance:
Normal Operation
Position 1 2345678910111213141516
+DDDDDDDDD* UUUCRLF
or –......... ***
or **********
*: Space
D: Digit or letter
U: Unit symbol
CR: Carriage return
LF: Line feed
Special Codes
Position 1 2345678910111213141516
******––******CRLF
or ******A******* CRLF
or ******AB ******CRLF
and only upon request with ESC w0 (no print command):
******S*XXXYYYCRLF
or ******I*XXX***CRLF
*: Space
AB = – –: Final readout mode A = C: Cal/adjustment
A = H: Overload S: Draft shield status
AB = H H: Overload in checkweighing I: Ionizer
A = L: Underload Y,Y,Y = Draft shield doors
AB = L L: Underload in checkweighing
XXX =
Decimal value calculated from individual status bits:
Decimal Binary Control
value value information
1
Bit0 = 0: No error/ionizer off
Bit0 = 1: Draft shield error/ionizer on
2
Bit1 = 0: Draft shield motor off
Bit1 = 1: Draft shield doors in motion
8
Bit3 = 0: Learning function off
Bit3 = 1: Learning function on
16
Bit4 = 0: At least one draft shield door open
Bit4 = 1: All draft shield doors closed
64
Bit6 = 0: Motorized draft shield operation
Bit6 = 1: Manual draft shield operation
Example for ME215/235/254/414/415/614:
R, M, L = COO: right door closed, middle and left doors open
R, M, L = OCC: right door open, middle and left doors closed
Example for ME5, SE2:
W 008210
Angle of aperature:
The draft has turned itself by 210°.
Control information:
0 → Bit 6 – Motorized draft shield operation
+0 → Bit 4 – Draft shield open
+8 → Bit 3 – Learning function on
+0 → Bit 1 – Draft shield motor off
+0 → Bit 0 – No error
=08
