General Specifications
Type of interface Serial point-to-point connector
Operating mode Asynchronous, full-duplex
Standard V28, RS-232C specification
Handshake mode*) 2-wire interface: via software (XON/XOFF)
4-wire interface: via hardware handshake lines with
Clear To Send (CTS) and Data Terminal Ready (DTR)
Transmission rates*) 150; 300; 600;1,200; 2,400; 4,800;
9,600;19,200 baud
Character coding 7-bit ASCII
Parity*) Mark, space, odd, even
Synchronization*) 1start bit;1or 2 stop bits
Data output format*) 16 or 22 characters
of the scale
Character format*) – 1start bit
– 7-bit ASCII
– 1parity bit
– 1or 2 stop bits
*) = can be changed by the user
4–2
