Sartorius SE2-F - Cabling Diagram

140
Cabling Diagram
– Diagram for interfacing a computer or other peripheral device to the balance using
the RS-232/V24 standard and cables up to 15 m (50 ft.) long
Balance Peripheral Device (PC)
Type of cable: AWG 24 specification
PC
25-pin or 9-pin
23
20 4
32
58
66
75
V24
