03025/03026
- 03 -
18
Resistance/continuity test
Diode test
Press and hold the yellow function
button at resistance position until “
Ω
”
or “ ” appears on the screen.
Press and hold the yellow function
button at resistance position until
“ ” appears on the screen
Measuring frequency
Note: Input voltage: 1V rms ~ 20V rms;
when the signal frequency becomes
higher, the input voltage required by the
meter will also increase.
Frequency measurement
(using head) only limited to 03026
Note
:
1. When using the head for
frequency measurement, please remove
all the probes from the meter.
2. Ensure the measured conductor is
clamped in the center of the head.
3. The measured current shall be 8A or
more.
