Operating Instructions SATA vision 2000
Description Version 1 Variant 2 and 3
Max. operating pressure 8,0 bar
Min. volumetric ow 170 Nl/min 240 Nl/min
Max. volumetric ow > 305 Nl/min
Operating temperature -6 °C – +60 °C
Storage temperature -20 °C – +60 °C
Max. tube length 40 m
Noise level with minimum-
volumetric ow
73 dB
Weight of breathing protection
hood
470 g
Weight of activated charcoal ab-
sorber
750 g
Weight of belt unit without activat-
ed charcoal absorber
260 g
8. First Use
The breathing protection hood is delivered in an assembled and opera-
tionally ready state.
Check after unpacking:
■ Breathing protection hood damaged.
■ Scope of supply complete (see chapter 5).
8.1. Installation on air supply
Variant 1, 2 and 3
Notice!
Use only approved compressed air supply hose (max. 40 m) with safety
quick-couplers for operation of the breathing protection hood.
Variant 1
