SATAM ZCM17 - Functionalities; General Arrangement of ZCM17; Version with Electronic Register


02/2018Edition 4/19 U518156‐en‐REV0

1. Functionalities
SatammastermetersmodelZCM17arededicatedtoperiodiccalibrationofcustodytransfer
measuringequipmentforfuelsandpe troleumproducts.
ZCM17isaworkingstandardthatcanbeusedregularlytocheckandcalibratemeasuring
instrumentsormeasuringsystems.


2. GeneralarrangementofZCM17

A. Versionwithelectronicregister

Release
valve
Electronic
register
Pressure
gauge
Release
valve
Drainage
pump
Connecting
pipe
PD meter
Connection to
flexible hose
