SATAM ZCM17 - Electronic Register EQUALIS S


02/2018Edition 7/19 U518156‐en‐REV0

ForcompleteinformationaboutZC17operationpleaserefertofollowingtechnicalmanuals:
Reference Technicalmanual
U508131 Description,installation,operation,servicingforZC17‐24andZC17‐48
U508334 Description,installation,operation,servicingforZC17‐80;ZC17‐150,ZC17‐250and
ZC17‐330

B. ElectronicregisterEQUALISS

The EQUALIS S Field Batch Controller depot version is an intelligent electronic
calculator/indicator, controlled by several embedded microprocessors, designed for efficient
managementoffluidmeasurement.Itcarriesoutthecalculation,displayandmanagementfunctions,
essentialtoproductloadingorunloading.
EQUALIS is designed to be
 used in an explosive atmosphere, with different protection modes, in
accordancewithdirectiveATEX94/9/CE.
Itisdesign edtoensurethedatabackupofthecurrentdeliveriesintheeventofapowerfailure.This
dataisrestoredassoonasthepowersupplyisrestored.
TheEQUALISuserinterface
includesa240x128pixelbacklitgraphicdisplay,a20‐keykeyboardand
StopandStartbuttons.
TheelectronicindicatorSEQUALISdepotversionconsistsofahousingcomposedoftwoelements.It
islocatedattheloadingpoint.Itconsistsoftwoboxes:
‐TheCalculatorModule(CMmodule),
‐TheHydraulicModule(HMmodule)fortheoutputcontrol.
The electronic indicator is supplied with 230VAC or 24VDC, It is equipped to communicate with
externalsupervisionsystems.

