Satec EM133 Reference Guide

18
Point
ID
Description
Options/Range
2
Units
2
Type
R/
W
Notes
0x161E
Not used
UINT32
R
0x161F
Not used
UINT32
R
0x1620
Not used
UINT32
R
0x1621
Not used
UINT32
R
0x1622
In Ampere demand
0-Imax
U2
UINT32
R
Total Energies
0x1700
kWh import
0-999,999,999
kWh
UINT32
R
0x1701
kWh export
0-999,999,999
kWh
UINT32
R
0x1702
Not used
INT32
R
0x1703
Not used
UINT32
R
0x1704
kvarh import
0-999,999,999
kvarh
UINT32
R
0x1705
kvarh export
0-999,999,999
kvarh
UINT32
R
0x1706
Not used
INT32
R
0x1707
Not used
UINT32
R
0x1708
kVAh total
0-999,999,999
kVAh
UINT32
R
0x1709
Not used
UINT32
R
0x170A
Not used
UINT32
R
0x170B
kVAh import
0-999,999,999
kVAh
UINT32
R
0x170C
kVAh export
0-999,999,999
kVAh
UINT32
R
0x170D
Not used
UINT32
R
0x170E
Not used
UINT32
R
0x170F
Not used
UINT32
R
0x1710
Not used
UINT32
R
0x1711
Not used
UINT32
R
0x1712
kvarh Q1
0-999,999,999
kvarh
UINT32
R
0x1713
kvarh Q2
0-999,999,999
kvarh
UINT32
R
0x1714
kvarh Q3
0-999,999,999
kvarh
UINT32
R
0x1715
kvarh Q4
0-999,999,999
kvarh
UINT32
R
Phase Energies
0x1800
kWh import L1
0-999,999,999
kWh
UINT32
R
0x1801
kWh import L2
0-999,999,999
kWh
UINT32
R
0x1802
kWh import L3
0-999,999,999
kWh
UINT32
R
0x1803
kvarh import L1
0-999,999,999
kvarh
UINT32
R
0x1804
kvarh import L2
0-999,999,999
kvarh
UINT32
R
0x1805
kvarh import L3
0-999,999,999
kvarh
UINT32
R
0x1806
kVAh total L1
0-999,999,999
kVAh
UINT32
R
0x1807
kVAh total L2
0-999,999,999
kVAh
UINT32
R
0x1808
kVAh total L3
0-999,999,999
kVAh
UINT32
R
V1/V12 Harmonics
1
0x1900
H01 Harmonic magnitude
0-10000
0.01
%
UINT16
R
