EM132-133 QUICK START GUIDE
BG0504 REV.A2
6
MODULE Installation
This section applies to the I/O and Communication modules.
Figure 5: PM130 PLUS modules
Figure 6: Mounting module
CAUTION!
Before I/O Module installation ensure that all incoming power sources are shut OFF. Failure to
observe this practice can result in serious or even fatal injury and damage to equipment.
NOTE:
Refer to the Installation and operation
manual for the wiring schematics
diagrams and setup parameters
MODULE
4 ANALOG OUT
MODULE
ETHERNET
MODULE
4DI/2DO
Module
Connector
Module Connector Cover
Remove Module Connector Cover
before assembling module
