Satec Expertmeter Series Reference Guide

35
5 Data Formats
Format
Code
Value
Description
Notes
Timestamp
F1
Local time in a UNIX-style format. Represents the
number of seconds since midnight (00:00:00),
January 1, 1970. The time is valid after January 1,
2000.
946684800 to
2145916799
allowed
Wiring Mode
F2
0
3OP2 - 3-wire open delta using 2 CTs (2 element)
1
4LN3 - 4-wire WYE using 3 PTs (3 element), line-to-
neutral voltage readings
2
3DIR2 - 3-wire direct connection using 2 CTs (2
element)
3
4LL3 - 4-wire WYE using 3 PTs (3 element), line-to-
line voltage readings
4
3OP3 - 3-wire open delta using 3 CTs (2 1/2
element)
5
3LN3 - 4-wire WYE using 2 PTs (2 1/2 element), line-
to-neutral voltage readings
6
3LL3 - 4-wire WYE using 2 PTs (2 1/2 element), line-
to-line voltage readings
8
3BLN3 - 3-wire broken delta using 2 PTs (2 1/2
element), line-to-neutral voltage readings
9
3BLL3 - 3-wire broken delta using 2 PTs (2 1/2
element), line-to-line voltage readings
Device Diagnostics
F23
Bit 0
Reserved
Bit 1
Reserved
Bit 2 = 1
RAM/Data error
Bit 3 = 1
CPU watchdog reset
Bit 4 = 1
Sampling fault
Bit 5 = 1
CPU exception
Bit 6
Reserved
Bit 7 = 1
Software watchdog reset
Bit 8 = 1
Power down
Bit 9 = 1
Device reset
Bit 10 = 1
Configuration reset
Bit 11 = 1
RTC fault
Bit 12
Reserved
Bit 13
Reserved
Bit 14
Reserved
Bit 15 = 1
EEPROM fault
Device Options
F28
Bit 0=1
Reserved
Bit 1=1
690V Option
Bits 2-5
Reserved
Bit 6=1
Analog output 0/4 or 4/20mA
Bit 7=1
Analog output 0-1mA
Bit 8=1
Analog output ±1mA
Bit 9=1
RO option
Bit 10=1
DI option
Bit 11=1
Reserved
Bit 12=1
Setup is secured by a password (authorization
required)
Bit 13=1
Reserved
Bit 14
Reserved
Bit 15
Reserved
Bits 16-18
Number of RO - 1
Bits 19-22
Number of DI – 1
Bits 23-24
Number of AO - 1
Bits 25-29
Reserved
Bits 30-31
Reserved
