SatKing PRO MAX - Mounting Plate Securing; Sealing and Tape Application

SatKing PRO MAX User manual - 17
B. Screw 6pcs of M4x20 bolt to x the mounting plate
Insert screws Re-apply silicone to cover bolts screwed
B-4
B-2
Place the mounting plate on the silicone and
make 6 holes (2mm) with a power drill
B-3
B-1
Apply silicone on the holes
C. Apply siliconebetween x bracket and friction tape
Remove friction tape and allow to dry
C-4
C-2
Apply silicone around mounting plate edge
C-3
C-1
Clean away the excess silicone
Prepare to place the antenna on to the four
upright bolts
