SatKing PRO MAX - Cable Holder Installation - Part 2

SatKing PRO MAX User manual - 19
F. Cable holder installation 2
F-2
controller cable and two(2) of receiver cables, cable holder and gland for installation
Place the assemble cable holder inside the tape
markings. Drill three(3) 2mm holes
Fix cable holder on the vehicle roof with
three(3) of M4 x 20 screws at drill holes made
F-4F-3
Apply silicone around cable holder and on the
top of the screws for waterproof
Connect cables to relative ports. Remove
friction tape then tidy silicone before dry
F-6F-5
F-1
Put the cable inside the Cable holder as above picture.
