Satlink ST-6502 User Manual

6
4. TECHNICAL SPECIFICATION
Modulator
Standard
DVB-T
Constellation
64QAM
Bandwidth
7 / 8 MHz
Carriers 8K
Guard Interval 1/32
Code Rate 2/3
MER >28 dB
Frequency Range 174 - 230 MHz, 470-862 MHz
RF Level 70 ~ 100 dBuV
Output Impedance 75Ω
HD
Compression H.264 - bitrate 5-15 Mb/s
Video Resolution
1920*1080_60P, 1920*1080_50P;
1920*1080_60i, 1920*1080_50i;
1280*720_60p, 1280*720_50P
Connector HD
General
Power Source DC 5V / 1A
Operating
Temperature
0 ~ +50°C
Dimensions 127mm(L) × 65mm(W) × 17mm(H)
Weight 195g
